Pneumatic Tools Pneumatic Tools

Cordless impact wrench Cordless impact wrench

Cordless impact wrench

9212 SPC Cordless impact wrench 18 V 9212 SPC Cordless impact wrench 18 V

• Illumination of the work area before the output begins to move C
• Extremely handy tool 1 Ú Y ^ N 5 è 4
• Light weight design Nm Nm rpm db (A) LpA
• Amperage without load: 5 A • Battery pack
• Li-ion rechargeable battery with very low self-discharge (only 2%) • Li-ion, 18 V, 5 Ah
compared to a standard NiMH rechargeable battery (15 - 25%) • For 9212-3 ∙ 9212 M-1 ∙ 9212 M-1/4 ∙ 9212 SPC-1 ∙ 9212 SPC-1/4
• Replacement battery: 9212-02 9230-2 ∙ 9230-2/4 ∙ 9233-7 ∙ 9233-7/4
• Net weight: 1.060 kg (without battery pack) 9212-05 – – – – 700 – 210367
• Battery net weight: 0.390 kg • Battery charger
• Battery charger net weight: 0.66 kg • For 9212-3 ∙ 9212 M-1 ∙ 9212 M-1/4 ∙ 9212 SPC-1 ∙ 9212 SPC-1/4
• Including belt clip, attachable on both sides, and hand strap 9230-2 ∙ 9230-2/4 ∙ 9233-7 ∙ 9233-7/4
• Total length: 167 mm 9212-03 – – – – 660 – 204823
• Height: 187 mm
• Width: 65 mm
• Recommended torque: 200 Nm 9212 M Mini cordless impact wrench 18 V
• Sound power level: 111 db(A) Lp W
• Vibration acceleration: 14.91 m/s 2 • High efficiency thanks to brushless motor
• Loosening torque (max) determined with screw size M: 16 • Handy, short and lightweight tool
• There are three power stages to choose from for torque acceleration
Stage 1: approx. 80 Nm at 700 rpm
Stage 2: approx. 150 Nm at 1600 rpm
Stage 3: approx. 220 Nm at 2500 rpm
• Amperage without load: 4.5 A
• Charging time ~ 35 minutes
• Brushless DC motor (BLDC):
– Longer service life, less wear, no need to change the carbon brushes
– High efficiency and hence less battery consumption
– More compact motor enables smaller dimensions
• Illumination of the work area before the output begins to move
• Li-ion rechargeable battery with very low self-discharge (only 2%)
compared to a standard NiMH rechargeable battery (15 - 25%)
• Net weight: 0.954 kg (without battery pack)
• Battery net weight: 0.365 kg
• Battery charger net weight: 0.66 kg
• Dimensions including rechargeable battery: 228 x 63 x 135 mm
• Including belt clip, attachable on both sides, and hand strap
• Recommended torque: 220 Nm
• Sound power level: 110.6 db(A) Lp W
• Vibration acceleration: 15.40 m/s 2
• Loosening torque (max) determined
with screw size M: 16

1 Nm Nm rpm db (A) LpA 5 è 4
^
Ú Y
N
• 3-piece set, contents:
cordless impact wrench, battery charger, Li-ion battery 9212-02 (1x)
9212 SPC-1 260 200 0 – 2700 100 1450 3 212439
• 4-piece set, contents:
cordless impact wrench, battery charger, Li-ion battery 9212-02 (2x)
9212 SPC-1/4 260 200 0 – 2700 100 – 4 214259
• Basic unit Cordless impact wrench set, without battery
9212 SPC-010 260 200 0 – 2700 100 1060 – 214273
• Battery pack
• Li-ion, 18 V, 2 Ah
• For 9212-3 ∙ 9212 M-1 ∙ 9212 M-1/4 ∙ 9212 SPC-1 ∙ 9212 SPC-1/4
9230-2 ∙ 9230-2/4 ∙ 9233-7 ∙ 9233-7/4
9212-02 – – – – 390 – 213788
B B
348 Valid until December 31, 2021 Components and spare parts from page 482 to 490
