Page 351 - HAZET英文2021

Pneumatic Tools Pneumatic Tools

Cordless impact wrench Cordless drilling machine / right-angle grinder

9212-1000 Cordless impact wrench 9212-1000 Cordless impact wrench

• High efficiency thanks to brushless motor C
18 V, 5 Ah 1 Ú Y ^ N 5 è 4
• Suitable for continuous operation Nm Nm rpm db (A) LpA
• Robust machine housing • Basic unit cordless impact wrench, without battery
• There are three power stages to choose from for torque acceleration 9212-1000 1400 1000 0 – 1800 101 3640 – 222711
Stage 1: approx. 180 Nm at 0-400 rpm
Stage 2: approx. 400 Nm at 0-800 rpm • Battery pack
Stage 3: approx. 1000 Nm at 0-1800 rpm • Li-ion, 18 V, 2 Ah
• Illumination of the work area before the output begins to move • For 9212-3 ∙ 9212 M-1 ∙ 9212 M-1/4 ∙ 9212 SPC-1 ∙ 9212 SPC-1/4
• Li-ion rechargeable battery with significantly lower self-discharge (only 9230-2 ∙ 9230-2/4 ∙ 9233-7 ∙ 9233-7/4
2%) compared to a standard NiMH rechargeable battery (15-25%) 9212-02 – – – – 390 – 213788
• Replacement battery: 9212-05 • Battery pack
• Battery net weight: 0.659 kg • Li-ion, 18 V, 5 Ah
• Battery charger net weight: 0.66 kg • For 9212-3 ∙ 9212 M-1 ∙ 9212 M-1/4 ∙ 9212 SPC-1 ∙ 9212 SPC-1/4
• Case net weight: 2.15 kg 9230-2 ∙ 9230-2/4 ∙ 9233-7 ∙ 9233-7/4
• Dimensions including rechargeable battery: 278 x 230 x 89.5 mm 9212-05 – – – – 700 – 210367
• Including belt clip, attachable on both sides • Battery charger
• Brushless DC motor (BLDC) • For 9212-3 ∙ 9212 M-1 ∙ 9212 M-1/4 ∙ 9212 SPC-1 ∙ 9212 SPC-1/4
– Longer service life, less wear, no need to change the carbon brushes 9230-2 ∙ 9230-2/4 ∙ 9233-7 ∙ 9233-7/4
– High efficiency and hence less battery consumption 9212-03 – – – – 660 – 204823
– More compact motor enables smaller dimensions
• Charging time with 5 Ah rechargeable battery approx. 80 min
• Sound power level: 112 db(A) Lp W 9213-1000 Cordless impact wrench
• Vibration acceleration: 17.80 m/s 2
• Loosening torque (max) determined with screw size M: 24 • High efficiency thanks to brushless motor
• Forward and reverse: multi-stage (right/left)
18 V, 5 Ah
• Suitable for continuous operation
• Robust machine housing
• There are three power stages to choose from for torque acceleration
Stage 1: approx. 180 Nm at 0-400 rpm
Stage 2: approx. 400 Nm at 0-800 rpm
Stage 3: approx. 1000 Nm at 0-1800 rpm
• Illumination of the work area before the output begins to move
• Li-ion rechargeable battery with significantly lower self-discharge (only
2%) compared to a standard NiMH rechargeable battery (15-25%)
• Replacement battery: 9212-05
• Battery net weight: 0.659 kg
• Battery charger net weight: 0.66 kg
• Case net weight: 2.15 kg
• Dimensions including rechargeable battery: 278 x 230 x 89.5 mm
• Including belt clip, attachable on both sides
• Brushless DC motor (BLDC)
– Longer service life, less wear, no need to change the carbon brushes
– High efficiency and hence less battery consumption
– More compact motor enables
smaller dimensions
• Charging time with 5 Ah rechargeable
battery approx. 80 min
• Sound power level: 112 db(A) Lp W
• Vibration acceleration: 17.80 m/s 2
• Loosening torque (max)
determined with screw size M: 24
• Forward and reverse: multi-stage (right/left)

1 Ú Y rpm db (A) LpA 5 è 4
N
^
Nm
Nm
• 3-piece set, contents:
cordless impact wrench, battery charger, Li-ion rechargeable battery (1x)
9212-1000/3 1400 1000 0 – 1800 101 3640 3 222674
• 4-piece set, contents:
cordless impact wrench, battery charger, Li-ion rechargeable battery (2x)
9212-1000/4 1400 1000 0 – 1800 101 3640 4 222681
B B
350 Valid until December 31, 2021 Components and spare parts from page 482 to 490
