Pneumatic Tools

Cordless impact wrench

9212 M Mini cordless impact wrench 18 V 9212 Cordless impact wrench set
C C
3

1 Ú Y rpm db (A) LpA 5 è 4
N
^
Nm
Nm
• 3-piece set, contents:
cordless impact wrench, battery charger, Li-ion battery 9212-02 (1x)
9212 M-1 270 220 0 – 2500 99.6 1340 3 212446
• 4-piece set, contents:
cordless impact wrench, battery charger, Li-ion battery 9212-02 (2x)
9212 M-1/4 270 220 0 – 2500 99.6 – 4 214266
• Basic unit Mini cordless impact wrench set, without battery
9212 M-010 270 220 0 – 2500 99.6 950 – 214280
• Battery pack
• Li-ion, 18 V, 2 Ah
• For 9212-3 ∙ 9212 M-1 ∙ 9212 M-1/4 ∙ 9212 SPC-1 ∙ 9212 SPC-1/4
9230-2 ∙ 9230-2/4 ∙ 9233-7 ∙ 9233-7/4
9212-02 – – – – 390 – 213788
N
Y
^
• Battery pack 1 Ú Nm rpm db (A) LpA 5 è 4
Nm
• Li-ion, 18 V, 5 Ah
• For 9212-3 ∙ 9212 M-1 ∙ 9212 M-1/4 ∙ 9212 SPC-1 ∙ 9212 SPC-1/4 • 3-piece set, contents:
9230-2 ∙ 9230-2/4 ∙ 9233-7 ∙ 9233-7/4 cordless impact wrench, battery charger, Li-ion battery (1x)
9212-05 – – – – 700 – 210367 9212-3 700 500 0 – 2000 99.4 1857 3 203444
• Battery charger • Battery charger
• For 9212-3 ∙ 9212 M-1 ∙ 9212 M-1/4 ∙ 9212 SPC-1 ∙ 9212 SPC-1/4 • For 9212-3 ∙ 9212 M-1 ∙ 9212 M-1/4 ∙ 9212 SPC-1 ∙ 9212 SPC-1/4
9230-2 ∙ 9230-2/4 ∙ 9233-7 ∙ 9233-7/4 9230-2 ∙ 9230-2/4 ∙ 9233-7 ∙ 9233-7/4
9212-03 – – – – 660 – 204823 9212-03 – – – – 660 – 204823
• Battery pack
• Li-ion, 18 V, 5 Ah
9212 Cordless impact wrench set • For 9212-3 ∙ 9212 M-1 ∙ 9212 M-1/4 ∙ 9212 SPC-1 ∙ 9212 SPC-1/4
9230-2 ∙ 9230-2/4 ∙ 9233-7 ∙ 9233-7/4
• High efficiency thanks to brushless motor 3 9212-05 – – – – 700 – 210367
18 V, 5 Ah
• There are three power stages to choose from for torque acceleration
Stage 1: approx. 80 Nm at 600 rpm and ~1700 beats per minute
Stage 2: approx. 300 Nm at 1400 rpm and ~2500 beats per minute
Stage 3: approx. 500 Nm at 2000 rpm and ~3400 beats per minute
• Illumination of the work area before the output begins to move
• Li-ion rechargeable battery with significantly lower self-discharge (only
2%) compared to a standard NiMH rechargeable battery (15-25%)
• Amperage without load: 5.5 A
• Replacement battery: 9212-05
• Net weight: 1.857 kg (without battery pack)
• Battery net weight: 0.659 kg
• Battery charger net weight: 0.66 kg
• Case net weight: 4.352 kg
• Dimensions including rechargeable battery: 204 x 64 x 259 mm
• Including belt clip, attachable on both sides
• Brushless DC motor (BLDC)
– Longer service life, less wear, no need
to change the carbon brushes
– High efficiency and hence
less battery consumption
– More compact motor
enables smaller dimensions
• Recommended torque: 500 Nm
• Sound power level: 110.4 db(A) Lp W
• Vibration acceleration: 20.30 m/s 2
• Loosening torque (max) determined with screw size M: 16
• Forward and reverse: multi-stage (right/left)
• Plastic box

B
