Pneumatic Tools Pneumatic Tools
Hot-air hand-held devices Hot-air hand-held devices
9233 Cordless right-angle grinder 9233 Cordless right-angle grinder
• High efficiency thanks to brushless motor C
1 ^ N 5 è 4
• Compatible with HAZET rechargeable batteries 9212-02 and 9212-05 K rpm db (A) LpA
• Ergonomic and compact housing design
• Device stops if the speed drops sharply due to canting • 3-piece set
1 cordless right-angle grinder
• Function against unintentional motor start when changing the battery 1 quick charger
• Mesh fabric protects motor from dirt 1 Li-ion rechargeable battery 18 V, 5 Ah
• Motor stop 2 seconds after switch-off 9233-7 345.1 8000 89 – – 218325
• Extremely flat head with low angle • 4-piece set
• Constant speed even during difficult work 1 cordless right-angle grinder
• Soft startup for greater comfort 1 quick charger
• Safety release lever 2 Li-ion rechargeable batteries 18 V, 5 Ah
• Lateral handle, to be used on left or right side 9233-7/4 345.1 8000 89 – 4 218950
• Including 1 protection cover each • Cut-off wheel set, 5 pieces
– for cut-off wheels • For 9233-7 ∙ 9233-7/4
– for rough grinding wheels
• Quick adjustment of protection cover without tools 9233-010/5 – – – – 5 219063
• Spindle thread: M 14 • Cut-off wheel set, 25 pieces
• Spindle lock • For 9233-7 ∙ 9233-7/4
• Weight with battery: 2.28 kg 9233-010/25 – – – – 25 219070
• Weight without battery: 1.53 kg • Rough grinding wheel set, 10-piece
• Vibration acceleration: 7.90 m/s 2 • For 9233-7 ∙ 9233-7/4
9233-011/10 – – – – 10 219087
• Basic unit cordless right-angle grinder, without rechargeable battery
9233-010 345.1 8000 89 – – 218943
• Battery pack
• Li-ion, 18 V, 2 Ah
• For 9212-3 ∙ 9212 M-1 ∙ 9212 M-1/4 ∙ 9212 SPC-1 ∙ 9212 SPC-1/4
9230-2 ∙ 9230-2/4 ∙ 9233-7 ∙ 9233-7/4
9212-02 – – – 390 – 213788
• Battery pack
• Li-ion, 18 V, 5 Ah
• For 9212-3 ∙ 9212 M-1 ∙ 9212 M-1/4 ∙ 9212 SPC-1 ∙ 9212 SPC-1/4
9230-2 ∙ 9230-2/4 ∙ 9233-7 ∙ 9233-7/4
9212-05 – – – 700 – 210367
• Battery charger
• For 9212-3 ∙ 9212 M-1 ∙ 9212 M-1/4 ∙ 9212 SPC-1 ∙ 9212 SPC-1/4
9230-2 ∙ 9230-2/4 ∙ 9233-7 ∙ 9233-7/4
9212-03 – – – 660 – 204823
Hot-air hand-held devices
1990 Hot-air tool
• Many extra functions S/
• Power: 2000 Watts
• Temperature range electronically-controlled and continuously adjustable
• Air flow range: 200– 550 l/min electronically-
controlled and continuously adjustable
• Menu navigation in 8 languages (D, ES, FR, GB, IT, NL, PT, SE)
• 6-piece set, contents:
heat gun, 1 stainless steel welding nozzle, 1 overlap welding nozzle,
1 solder sleeve reflector nozzle and 1 reflector nozzle, 1 pressure roller
• 7 preset programmes for welding of plastic material (select the desired
programme – temperature and air flow will be set automatically)
• Adjusting of the current temperature
through closed electronically-controlled
system, using different nozzles
• Stand-by mode (low power consumption
at constant temperature)
• Sucked in air is not blown through
the motor – preventing dirt from
contaminating the motor
• 14 preset programmes
• Ergonomic design – even distribution
of weights – may stand upright
• Protected heating element
ensuring optimal isolation
• LCD display
• Plastic box
• Temperature range:
80°C – 650°C
9233-010/5 9233-010/25 9233-011/10
B B
352 Valid until December 31, 2021 Components and spare parts from page 482 to 490
