Page 352 - HAZET英文2021

Pneumatic Tools

Cordless drilling machine / right-angle grinder

9213-1000 Cordless impact wrench Cordless drilling machine /
right-angle grinder
C

9230 Cordless drilling machine
• High efficiency thanks to brushless motor

• 18 V, 2 Ah
• Compatible with HAZET rechargeable
batteries 9212-02 and 9212-05
• Tool-free metal quick-clamping drill chuck 1-13 mm
• Selectable torque stages 15 + 1 drilling
• Revolutions per minute Step 1: 0–560
Revolutions per minute Step 2: 0–1900
• Vibration acceleration screwing: 0.8 m/s 2
Vibration acceleration drilling: 2.3 m/s 2
• Robust machine housing
• Suitable for continuous operation
1 Ú Y ^ N 5 è 4 • Including belt clip, attachable
on both sides
rpm
Nm
Nm
db (A) LpA
• Weight with battery: 1.68 kg
• 3-piece set, contents: Weight without rechargeable
cordless impact wrench, battery charger, Li-ion battery (1x) battery: 1.27 kg
9213-1000/3 1400 1000 0 – 1800 101 3700 3 222704 • Brushless DC motor (BLDC):
• 4-piece set, contents: – Longer lifetime, less wear, no change
cordless impact wrench, battery charger, Li-ion battery (2x) of the carbon brushes required
9213-1000/4 1400 1000 0 – 1800 101 3700 4 222797 – Greater efficiency and thus less
battery consumption – More
• Basic unit cordless impact wrench, without battery compact motor allows for smaller
9213-1000 1400 1000 0 – 1800 101 3700 – 222698 installation dimensions
• Battery pack • Plastic roll
• Li-ion, 18 V, 2 Ah
• For 9212-3 ∙ 9212 M-1 ∙ 9212 M-1/4 ∙ 9212 SPC-1 ∙ 9212 SPC-1/4
9230-2 ∙ 9230-2/4 ∙ 9233-7 ∙ 9233-7/4
9212-02 – – – – 390 – 213788
• Battery pack
• Li-ion, 18 V, 5 Ah
• For 9212-3 ∙ 9212 M-1 ∙ 9212 M-1/4 ∙ 9212 SPC-1 ∙ 9212 SPC-1/4
9230-2 ∙ 9230-2/4 ∙ 9233-7 ∙ 9233-7/4
9212-05 – – – – 700 – 210367
• Battery charger
• For 9212-3 ∙ 9212 M-1 ∙ 9212 M-1/4 ∙ 9212 SPC-1 ∙ 9212 SPC-1/4
9230-2 ∙ 9230-2/4 ∙ 9233-7 ∙ 9233-7/4
9212-03 – – – – 660 – 204823

1 Y db (A) LpA 5 è 4
N
Nm
• 3-piece set
1 cordless drilling machine
1 quick charger (40 minutes)
1 Li-ion rechargeable batteries 18 V, 2 Ah
• Delivered in a robust bag
9230-2 60 68 – 3 218370
• 4-piece set
1 cordless drilling machine
1 quick charger (40 minutes)
2 Li-ion rechargeable batteries 18 V, 2 Ah
• Delivered in a robust bag
9230-2/4 60 68 – 4 218967
• Basic unit cordless drilling machine, without
rechargeable battery, without charger
9230-010 60 68 – – 218974
• Battery pack
• Li-ion, 18 V, 2 Ah
• For 9212-3 ∙ 9212 M-1 ∙ 9212 M-1/4 ∙ 9212 SPC-1 ∙ 9212 SPC-1/4
9230-2 ∙ 9230-2/4 ∙ 9233-7 ∙ 9233-7/4
9212-02 – – 390 – 213788
• Battery pack
• Li-ion, 18 V, 5 Ah
• For 9212-3 ∙ 9212 M-1 ∙ 9212 M-1/4 ∙ 9212 SPC-1 ∙ 9212 SPC-1/4
9230-2 ∙ 9230-2/4 ∙ 9233-7 ∙ 9233-7/4
9212-05 – – 700 – 210367
• Battery charger
• For 9212-3 ∙ 9212 M-1 ∙ 9212 M-1/4 ∙ 9212 SPC-1 ∙ 9212 SPC-1/4
9230-2 ∙ 9230-2/4 ∙ 9233-7 ∙ 9233-7/4
9212-03 – – 660 – 204823

Components and spare parts from page 482 to 490 Valid until December 31, 2021 351
