Torque Technology Torque Technology

SYSTEM 6000 CT SYSTEM 6000 CT

6000-1 CT Torque wrench ∙ SYSTEM 6000 CT ∙ ± 3% accuracy (6170-1 CT 4%) ∙ 400 – 2000 Nm

Made in Germany /
• For highest torque values
• ± 3 % accuracy of scale value (in direction of actuation) (6170-1 CT ± 4%)
• Ideal for industrial climbers
• Application on wind turbines, dockyards, in the aviation and
heavy industries, on commercial vehicles etc.
• To be disassembled in two parts (6170-1 CT: three parts) with release tool
• Bag included for safe storage and for carrying or wearing on your back
• Fast screw tightening also possible with ratchet shaft. For
torque tightening always use the complete wrench
• 2-component handle for improved feel
• Simplified locking for adjusting the torque value
• Viewing window for visual checking of the locking
• 3 additional coloured coding rings for markings in the
case of personalisation or special workflows
• DIN EN ISO 6789-2:2017, DIN 3120, ISO 1174-1

1 Output K 1 5 Release accuracy ! Å Nm transmitter # 4
Signal
tolerance %
1000 Nm Torque wrench
Weight only approx. 10 kg
• Actuating force only 590 N (60 kg) at 1000 Nm
• Length of ratchet shaft 903 mm, handle 930 mm
6150-1 CT i 20 = ⁄4″ 1789 36 77 3 400 – 1000 5  24.2 – 61.0 141067
3
1600 Nm Torque wrench
Weight only approx. 14 kg
• Actuating force only 685 N (70 kg) at 1600 Nm
• Length of ratchet shaft 1205 mm, handle 1320 mm
6160-1 CT i 25 = 1″ 2455 36 77 3 600 – 1600 5  26.1 – 70.1 155316
2000 Nm Torque wrench
Weight only approx. 18 kg
• Actuating force only 685 N (70 kg) at 2000 Nm
• Calibration according to company standards
6170-1 CT i 25 = 1″ 3033 36 77 4 800 – 2000 6  27.9 – 70.1 177776
• Torque wrench including DAkkS calibration certificate
6150-1 CT CAL i 20 = ⁄4″ 1789 36 77 3 400 – 1000 5  24.2 – 61.0 193059
3
6160-1 CT CAL i 25 = 1″ 2455 36 77 3 600 – 1600 5  26.1 – 70.1 193066
282 Valid until December 31, 2021 Components and spare parts from page 482 to 490
