Page 280 - HAZET英文2021

Torque Technology

SYSTEM 5000 CT

5200-3 CT Torque wrench ∙ SYSTEM 5200-3 CT (with insert square) ∙ ± 3% accuracy ∙ 10–200 Nm

Made in Germany
• Plug-and-socket connection to hold insert tools
• Accuracy ± 3% of scale value (in direction of actuation)
• Safety:
– Haptic (close-gap release)
– Audible (“click” sound)
• Designed for rough workshop use
• Wide range of applications for controlled screw tightening in tyre
service, bicycle, passenger car and commercial vehicle applications
as well as various applications in trade and industry
• Optimised sealing ring to protect against debris
• Handle with better grip for easier power transmission
• Adjustment aid with detent points for optimised operator guidance ensures
safe and fast adjustment of the desired torque value by turning the handle
• Safe locking of the setting values by latching function on the rotary assembly
• Rotary assembly in triangular form prevents uncontrolled rolling
• Lock symbols indicate the respective locking status
• Can be attached to the cable loop through openings on the locking rotary assembly
• Easy-to-read, high-contrast scale
• Permanent readability due to laser marking on the scale bush
• Tested in accordance with DIN EN ISO 6789-2:2017
• With calibration certificate and serial number
• Delivery in sturdy Hexa plastic box
• DIN EN ISO 6789-2:2017

1 Output K M 1 5 Release accuracy ! Å Nm # 4
tolerance %
5290-3 CT ) 9 x 12 291 245 17 22 3 10 – 60 0.5 3.7 – 23.4 228904
5292-3 CT ) 14 x 18 484 422 23 30 3 40 – 200 1 8.9 – 46.6 228911

Components and spare parts from page 482 to 490 Valid until December 31, 2021 279
