325, 326
SEPARATORS AND TAPERED BLADES

³ for pulling off ball and roller bearings and
close-fitting components
³ zinc-plated, spindles gunmetal-finish
³ high grade tool steel

Ø Pieces Weight/g
Code Number for separator w k
mm U V
0325000606100 325-60 5-60 326-45 17 M12 1 390
0325000756100 325-75 12-75 326-45 19 M12 1 650
0325001156100 325-115 22-115 326-80 24 M16 1 1753
0325001506100 325-150 25-155 326-100 30 M20 x 1,5 1 3900
0326000456100 326-45 45-140 - 17 M12 1 1027
0326000806100 326-80 55-205 - 22 M16 1 2800
0326001006100 326-100 90-260 - 22 M20 x 1,5 1 5000

177-...
PULLER
³ for pulling off ball bearings, gear-wheels, v-belt pulley etc.
³ heavy-duty, forged pattern
³ 3 arms
³ zinc-plated, spindle gunmetal-finish
³ high grade tool steel

Span Width Span Depth Pieces Weight/g
Code Number a mm b mm c mm d mm w
mm mm U V
0177001006100 177-100 18-100 85 2 8 20 17 12 1 500
0177002006100 177-200 20-200 150 3 12 25 18 17 1 1700
12 0177002506100 177-250 35-250 220 3 18 32 18 19 1 3900
0177003006100 177-300 50-300 250 5 22 50 30 22 1 7300
0177003506100 177-350 50-350 350 5 22 50 30 22 1 8300
0177004006100 177-400 50-400 400 5 22 50 30 22 1 8800
0177004506100 177-450 50-450 450 5 22 50 30 22 1 9400
0177005006100 177-500 50-500 500 5 22 50 30 22 1 10000

466
