324S15
WINDSCREEN WIPER ARM PULLER SET

³ 15 pcs.
³ for removing screen wiper arms
³ heavy-duty, forged pattern
³ zinc-plated, spindle gunmetal-finish
³ high grade tool steel
³ in black plastic box 260 x 210 x 68 mm
with a plastic foam insert

324S15.
JPG

Code Number Contents Width mm Depth mm Height mm Pieces Weight/g
U V
0324501506100 324S-15 1 Bridge with spindle 260 68 210 1 2250
1 puller with hooks
2 special hooks
1 spindle support
1 hollow push piece for wipes with
water jet in the centre of the hub
1 spindle extension
8 hooks

325S-...
PULLER/SEPARATOR SET
³ containing one puller, one separator and
one set of drawbar extensions
³ zinc-plated, spindle gunmetal-finish
³ dimensions:
25S-60, 325S-80: 265 x 197 x 45 mm
325S-100: 380 x 285 x 60 mm
325S-150: 417 x 380 x 75 mm

Code Number Contents Opening mm Span Ø mm Pieces Weight/g
U V
0325500606100 325S-60 Extension 150 5-60 1 2400
1 piece each 325-60, 326-45 12
0325500806100 325S-80 Extension 150 12-75 1 2980
1 piece each 325-75, 326-45
0325501006100 325S-100 Extension 210 22-115 1 7480
1 piece each 325-115, 326-80
0325501506100 325S-150 Extension 315 25-155 1 12920
1 piece each 325-150, 326-100

info@elora.de www.elora.de 469
