314S3
V-BELT PULLEY PULLER SET

³ 15 pcs. for following applications:
³ Variant 1 for V-belt pulleys with threaded holes
³ 1 short beam for V-belt pulleys Ø 43-120 mm
³ 1 long beam for V-belt pulley Ø 95-210 mm
³ 3 exchangeable push-pieces to use as spindle extension
³ Variant 2 for V-belt pulley without threaded holes
³ 1 short beam for V-belt pulleys Ø 24-100 mm
³ 1 long beam for V-belt pulley Ø 85-195 mm
³ Hooks for narrow spaces for clamping depth up to 68 mm, respectively
extension up to 88 mm
³ Variant 3 with 2 hooks to reach the rills of the V-belt pulley
³ 1 short beam for V-belt pulleys Ø 80-140 mm
³ 1 long beam for V-belt pulley Ø 135-235 mm
³ in a black plastic case 260 x 210 x 62 mm
³ high grade tool steel, zinc-plated
³ spindle and push-pieces gunmetal-finish

Code Number max. Span Width mm max. depth mm Pieces Weight/g
U V
0314500306100 314S3 195 88 1 2740
172-...
PULLER
³ 2 legs, heavy-duty pattern, silver-coloured, puller legs to be used on both sides:
one side with wide, the other side with narrow hooks
³ zinc-plated, spindles gunmetal-finish
³ high grade tool steel

Span Width Opening Pieces Weight/g
Code Number a mm b mm c mm d mm w
mm mm U V
0172001506100 172-150 20-150 2 9 21 12 85 17 1 900
0172002006100 172-200 40-220 4 11 25 21 130 19 1 2100

173-...
STANDARD PULLER
³ heavy forged pattern
³ 2 arms
³ by turning the puller hooks usable as external and internal puller
³ zinc-plated, spindle gunmetal-finish
³ high grade tool steel

(further sizes on request)
External Tension Interal Tension Span depth Pieces Weight/g
Code Number a mm b mm c mm d mm w
mm mm mm U V
0173000806100 173-80 20-90 70-130 100 3 13 25 20 17 1 1100
0173001306100 173-130 25-130 80-180 100 3 13 25 20 17 1 1200
0173001606100 173-160 50-160 105-220 150 4 16 35 25 22 1 2860 12
0173002006100 173-200 60-200 120-270 150 4 16 35 25 22 1 3420
0173002506100 173-250 80-250 160-330 200 5 25 54 35 27 1 7480
0173003506100 173-350 80-350 160-420 200 5 25 54 35 27 1 8600
0173005206100 173-520 110-520 195-600 200 5 25 54 35 27 1 13000
0173006406100 173-640 140-640 225-715 225 5 25 54 35 27 1 23160
