'PS TBGFUZ VTF

CAUTION

˔ When using torque wrenches, grip right position and rotate in a fig.3
clockwise direction only. Failure to follow this instruction may affect
measurement value. (fig.3)

TORQUE WRENCH

˔ Do not bang or disassemble torque wrenches.
Do not use torque wrenches in water.
Do not store torque wrenches at high-temperature, humidity and
dusty place.

˔ Never apply torque with quick motion or putting weight on the fig.4
torque wrench. (fig.4)

What is torque?

Force moment is described as T(torque) = F(force)×L(length).

Gravity Units are kgf·m, kgf·cm
SI Unit is N·m
1kgf·m=9.807N·m
1N·m=0.10197kgf·m

T(torque) = F(force)×L(length).

472
