Electric tire wrench 8-90TW Series option.

Electric Tire Wrench ideal for use with the 8-90 TW series.
By replacing the reaction force support, both JIS method (6 & 8 hole wheel) and new ISO method (8 & 10 hole wheel) can be supported.
Models Descriptions
DT9TWT Digitorqon (TW-type)
TWL Lever type reaction arm
TWL8H Cup type reaction arm JIS for 6/8 holes
TWL10H Cup type reaction arm ISO for 10 holes
TWLPP Protector- (for TWL)
TWLTR Clamp for pistol types
TWLHR Handle for straight types
※ Turn to P.416 for the details of Digitorque (TW type).
TWL TWLPP

TWL8H TWL10H
DT9TWT
Image of digitorqon installation

※ "Digitorqon" is a registered trademark of TONE Corporation.
TWLTR TWLHR

Electric tire wrench wheel nut combination socket (12pt.)

Plating is hard to peel off with electroless plating. Workability Across
Qty./
improved for wheel nut fitting with 2 shapes in one socket Models Flat Dimensions (mm) Carton Weight
(hexagon and square). In the 8ED-4121A, the double hexagonal (mm) (Generally) (g)
L
d
L1
L2
D2
S1×S 2
D1
part has a shape of one-throw skipping, further improving the 41 × 21 57 48 12.5 42.5 90 33
insertion workability. 8ED-4121 5 840
8ED-4121L 41 × 21 57 48 16.0 42.5 90 33 5 850
41 × 21 57 48 12.5 42.5 90 33
8ED-4121A
25.4 For bus/truck ※ This product is registered design. 5 840
mm
1
8ED-4121
-4121L
8ED-4121A
8ED-4121A

■ Pin/O-ring compatible chart
Models 8ED- 4121, 4121L, 4121A
Pin PIN5544S
O-ring RINGW30RS
8ED-4121L 8ED-4121
※ Within a plastic bag (10 pcs./pkg.)
