%JHJUPSRPO GFBUVSFT 58 UZQF

Tightening torque is gauged with to load on an electric tire wrench, and it's the torque indicator it's possible to check.
Tightening torque of the two directions of rotation can be measured.

An installation exampleɿ
8ED4121L ʴ DT9TWT ʴ 8-90TWLAA
⁠

1 Workability improvement 4 Power off prevention 7 Overload notification

function
The power will be turned off automatically after
Digitally display of tightening torque allows
2 minutes of inactivity.
safe and reliable operation.
2 Easy operation 5 Power saving function 8 Battery replacement
All operations can be done with only one button
such as power ON / OFF, reset and data
seconds after measurement and then changes
redisplay. The tightening torque data is displayed for 10 notification function
3 Digital display 6 Zero point adjustment function 9 Torque measurable both
to with low power consumption.
ʵ ʵ ʵ ʵ
It is also possible to display again.
Digital display of tightening torque. Simple and
CW and CCW
reliable confirmation of tightening torque is possible.
Zero point adjustment is possible just by
pressing the pushbutton before measurement.
Digital display
DIGITORQON (TW TYPE) Calibration Certificate Included

Test Report Traceability
Chart
For electric tire wrenches

DT7TWT DT9TWT

Torque capacity Accuracy Min. Continuous Temp./ Main body
Models Battery type Suitable model
(N･m) (%) display usage limits humidity range weight (kg)
DT7TWT 350～750 ± 4 2 0-40 ℃ 80%RH Below TONE Electric tire wrench 1.7
ETW70 series.
AAA Alkaline Battery x 4 About 2100 times (It doesn't condense into dew.) TONE Electric tire wrench
DT9TWT 400～900 ± 4 2 2.4
8-90TW series.
※ Patent Design Registered.
Accessory

L-type hex wrench (4mm) 1
(-) Screwdriver 1
Single 4 Shape alkaline batteries. 4
Instruction manual 1 ̧̥̤̬̚
̤̣ʗ̛̛̤
Calibration cert. (with traceability) 1 ̧̚ʵ̡̡̘̖ ̌̕ ̌̌ ̣ɾ̼
̧̚ʵ̨̩̚
Case 1
※ A battery for bundling sometimes has
the short life. ୯Ґ NN
DT7TWT DT9TWT
Expiration date of calibration cert.
I
1. When not in use, the product can stay up to 1 year after calibration 2. f the usage started after 1 year from calibration date, it can be used
date mentioned in the certificate. up to 1 year since the first usage or up to 10,000 tightening times.
Check & Repair
Torque devices require regular inspection (once a year or 10,000 times afterwards). Checking service is available with service charge.
※ "Digitorqon" is a registered trademark of TONE Corporation.
