MEASURING: DIAL TEST INDICATOR GAUGES

Magnetic Bases
CM6416 Magnetic Holder GA3JAMB Triple Joint Arm Magnetic Base
• Magnet has on/off switch • This versatile indicator holder has three SHOP
• Base is 2-3/8 x 1-7/8 x 2-1/2ʺ pivots available for positioning the
• Post is 7 x 15/16ʺ indicator where needed
• Rod is 6 x 25/64ʺ • All pivots are controlled by one
• Will grip flat or curved metal surfaces tightening knob CM6416
GA1FPMB Flex-O-Post Magnetic Base • Works with any indicator with a 3/8ʺ
• Complete assembly is for use with all test, (9.5 mm) stem, standard dovetail mount,
back-plunger, AGD, dial and miniature body clamp or with a 1/4ʺ (6.3 mm) or
dial indicators 3/16ʺ (4.7 mm) shank
• The flexible post is an assembly of short • The working area is within a hemisphere
tubular steel sections and precision ball having a radius of approximately GA1FPMB
joints, linked by an internal steel cable 12ʺ (300 mm)
• The indicator snug on the end of the post • The very sensitive fine-adjustment is
can be rotated through 360° and locked located on the magnetic base to
in any position eliminate indicator deflection when
• This makes it possible to use indicators it is being adjusted
in awkward places that are hard to reach
with conventional holding devices
• Assembled to the magnetic base, the
post has a vertical reach of approximately EQUIPMENT
15ʺ (380 mm) and a horizontal reach of
approximately 10ʺ (250 mm)
• The base has three precision-ground GA3JAMB
magnetic contact surfaces
• V-step holds base to arbors,
shafts, chucks
LEVELS

TL900L 9ʺ Aluminum Lighted Level YA328A Magnetic Angle Locator
(Blue-Point ) (Blue-Point )
®
®
• Lighted level for more accurate readings • Ideal for checking the drive shaft angle
under all conditions • Red degree indicator is located behind TL900L
• Machined Billet Aluminum for the numbers for exact reading of
added durability graduations
• Rare earth magnets attach to • SAE and metric scales molded into the
ferrous surfaces base of the tool are 1/8ʺ and centimeters
• 45°, 90° and 180° scales for flexibility • Large 1-7/8 x 7/8ʺ magnet in the base for
• Auto shut-off feature after ten minutes secure retention
extends battery life
• Uses two AAA alkaline cells (included)
• Sight glasses are backlit for
better visibility
YA328A

MEASURING: FEELER GAUGES

Feeler Gauges, Ignition
Blade
No. of
Stock No. Dimensions, Blade Size, inches Increments Description
Blades
inches
Short Blade, Ignition Gauge
.010, .012, .013, .015–.022,
FB316B ‡ 18 1/4 x 1-3/4 .024–.026, .028, .030, .032, .035 .001ʺ Set, Double Stamped with FB316B
SAE and Metric Sizes
.003, .004, .005, .006, .007, .008,
FB326B ‡ 26 1-1/2 x 3, .010, .012, .013, .015, .017, .018, .001ʺ Double Stamped with SAE
1/4 x 1-3/4 .020, .022, .024 .026, .028, .030, and Metric Sizes
.032, .035
FB326B
