MEASURING: THREAD IDENTIFICATION

T60K SHOP
T27GS T28GM
Thread Identification
T1DG T60K Thread Measurement Kit
T1DG Drill Gauge
• Leaves the right amount of stock for approximately • Drill gauge with both SAE and metric thread pitch gauges
65% full thread in one kit
• Easy-to-read white lettering on matte black finish • Drill gauge provides correct sizing of a tap drill for any
• Shows correct drill body size commonly sized machine screw tap in NF National Fine or NC
• 60 holes with number sizes and decimal equivalents National Coarse Thread Series (numbers 1–60 and .228–.040ʺ)
• Made of hardened steel to resist wear • Leaves on most gauges have a special narrow design,
permitting checking of internal threads and external threads
• Tested for accuracy and hardening • Leaves the right amount of stock for approximately 6
T27GS SAE Thread Gauge 5% full thread
• 27 leaves • Easy-to-read white lettering on matte black finish
• 1/4ʺ-28 TPI • Shows correct drill body size
T28GM Metric Thread Gauge • 60 holes with number sizes and decimal equivalents
• 28 leaves • Made of hardened steel to resist wear
• .25–2.5 mm • Tested for accuracy and hardening EQUIPMENT
• Quickly determine the pitch of various threads • Clearly graduated on polished finish
• Leaves on most gauges have a special narrow • Locking device
design, permitting checking of internal threads as • Fits in your pocket
well as external threads • Packaged in red plastic box with foam insert
• Clearly graduated on polished finish
• Locking device
MEASURING: MEASURING SETS

COMBOSQ3
Measuring Sets SQUAREB12 SQUARECOMB12
COMBOSQ3 Combination Square SQUAREB12 Machinist s Measuring SQUAREB180 Protractor Head (180°)
• Includes reversible lock bolt, scriber, Set (Blue-Point ) (Blue-Point )
®
®
spirit level in both square head and • Includes SQUAREB90 sliding head • Protractor is graduated 180° in
protractor head and RULER12BSQ steel rule in fitted both directions
• Direct reading double storage case • Includes bubble level
180° protractor SQUARECOMB12 Combination RULER12BSQ 12ʺ Steel Rule
• Forged and hardened steel heads ® ®
with smooth black enamel finish Measuring Set (Blue-Point ) (Blue-Point )
• Spring-tempered steel blade • Includes SQUAREB180 protractor, • Precision ground and hardened steel
• Blade has non-glare satin RULER12BSQ steel rule plus blade for greater accuracy
chrome finish SQUAREB90 and SQUAREB45 sliding • Graduated in 1/8ʺ and 1/16ʺ
• Blade has deep, black filled, heads in fitted storage case increments on one side and 1/32ʺ
chemical machined graduations SQUAREB90 Sliding Head (90°) and 1/64ʺ increments on the other
®
that will last a lifetime (Blue-Point ) SQUAREB45 Sliding Head (45°)
• Supplied in protective plastic case • 90° square head with bubble level (Blue-Point )
®
with foam insert and scriber points • Center head for 45° angles only
MEASURING: STRAIGHT EDGES AND STEEL RULES

Precision Straight Edges
• Use with feeler gauges to check for
distortion in engine blocks, cylinder GA435 GA438A GA535
heads, flywheels, main bearing
saddles, cam bearing saddles, cam GA435 Precision Straight Edge • Precision working edge ground to
covers and bell housings • Wide range of applications within .0002ʺ per 12ʺ in length
• Precision working edge ground to GA438A 24ʺ Precision Straight Edge • Great stability with 1/4ʺ thickness
within .0002ʺ per 12ʺ in length • Use with feeler gauges to check for and 1-1/2ʺ width
• Great stability with 1/4ʺ thickness distortion in engine blocks, cylinder • Convenient hanging hole and
and 1-1/2ʺ width heads, flywheels, main bearing edge protector
• Convenient hanging hole and saddles, cam bearing saddles, cam GA535 Precision Straight Edge
edge protector
covers and bell housings • 35ʺ long
801
• Read safety precautions on pages W1 to W4
