MEASURING: DIAL TEST INDICATOR GAUGES
EQUIPMENT

GA3640 GA3634 GA3645 GA3450
Dial Test Indicator Sets
GA3640 Long Range Dial Test Indicator Set GA3645 Long Range Dial Test Indicator Set
• All-purpose indicator set • All-purpose indicator set
• Indicator with 0–1ʺ range and .0005ʺ graduations • Indicator with 0–1ʺ range and .0005ʺ graduations
• Easy-to-read white on black dial face • Easy-to-read white on black dial face
• Magnetic base attaches to flat surface • Conforming magnetic base for more mounting options
• Checks ball joint, tie rod, cam and valve guide wear, • Checks ball joint, tie rod, cam and valve guide wear,
wheel rim, flywheel and disc brake runout wheel rim, flywheel and disc brake runout
• Dial is continuous with revolution counter • Dial is continuous with revolution counter
• Bezel may be rotated for any setting point • Bezel may be rotated for any setting point
• Base includes adjustable swivel clamp for post and rod
• Includes powerful magnetic base with post, stepped
SHOP • Includes storage case • Allows quick and accurate pinion depth set for all
rod and clamps along with contact, rod connector and
• Includes storage case
indicator holding clamp
GA3450 Universal Pinion Depth Gauge
GA3634 Ball Joint/Disc Brake Test Indicator Set
aftermarket gear sets
• All-purpose indicator set
• Works on OEM gear sets with pre-measurement of
• Perfect for general use
pinion depth
• Incorporates a swing arm assembly and indicator holder
• Indicator with 0–1ʺ range and .0005ʺ graduations
• Easy-to-read white on black dial face
• Indicator and three precision setting masters
• GA3640 uses a fixed magnetic base
• GA3450 is also included in the GA3460 Master
• GA3645 uses a conforming magnetic base for more
Rear Axle Set
mounting options • Gauge and components are stored in CM6547050 Case
• GA3634 uses locking pliers and a flexible gooseneck for CM6564550 Storage Case
non-magnetic applications and difficult areas • Fits GA3645 long range dial test indicator set
• Ideal for brake and undercar work
Dial Test Indicator Set Specifications
Stock No. Range Graduations Reading
GA3640 1.00ʺ .0005ʺ 0–50
GA3645 1.00ʺ .0005ʺ 0–50
GA3634 1.00ʺ .0005ʺ 0–50
GA3450 0.00–4.00ʺ .0005ʺ 0–50

GA3601
GA3625A GA3609
Timing Gauges Contact Points and Extensions
GA3625A Timing Gauge (Blue-Point ) GA3601 Dial Indicator Extension
®
• Two-cycle and small engine timing gauge • Use with GA3400, GA3634, GA3640 and GA3645 dial test indicators
• 0–1ʺ indicator with 0.001ʺ graduations • 4-48 female thread allows the extension of any contact point for
• Easy-to-read black on white dial face special applications
• 14 and 18 mm adaptors included • 6ʺ long
• For finding top dead center GA3609 8 pc Contact Point and Extension Set
• Use with GA3400, GA3634, GA3640 and GA3645 dial test indicators
• 4-48 female thread allows the extension of any contact point for
special applications
• Extensions can be joined together to extend reach
• Contact points feature a polished tip with radius end and are
manufactured from hardened steel
796 • Includes (4) 1ʺ extensions, (4) contact points (0.2, 0.4, 0.6 and 0.8ʺ)
plus holder for set components
