PISTON: SERVICE TOOLS
EQUIPMENT

Ring Expanders
®
PRS8 Piston Ring Expander (Blue-Point )
• Installs piston rings from 3/64–1/4ʺ thick
• Eliminates breakage or distortion of rings
• 7ʺ long
PRS8
PRS10 ‡ Piston Ring Expander (Blue-Point )
®
• 2-3/4ʺ–4-1/4ʺ ring capacity
• Remove or install both step cut and diagonal cut rings
• Spring tension eliminates the need for adjustment
PRS10
®
PRS12 ‡ Piston Ring Expander (Blue-Point )
• Similar to PRS10 but with 4-1/2–7ʺ ring capacity
• Excellent for heavy-duty diesel applications
Ring Groove Cleaners
RC510A Piston Ring Groove Cleaner (Blue-Point )
®
RC510A
• For pistons with grooves of 5/64, 3/32, 1/8, 5/32 and 3/16ʺ
with diameters from 1–5ʺ
SHOP Ring Compressors ® ®

RC150A Ring Compressor (Blue-Point )
• Four band
• 3-1/2–7ʺ capacity, 7ʺ deep
RC50C Ring Compressor (Blue-Point )
• Two band
• 3-1/2–7ʺ capacity, 3-1/2ʺ deep
®
RC40C Ring Compressor (Blue-Point )
• Two band
• 2-1/8–5ʺ capacity, 3-1/2ʺ deep
®
RCL30 Ring Compressor (Blue-Point )
RC150A • One band
RC50C
• 2-1/2–5ʺ capacity
• May be disassembled and removed from around connecting rod
when used on small aircraft, motorcycle or other engines that
require the cylinder to be pushed over the piston during assembly
®
RCW60 Ring Compressor (Blue-Point )
• One band
• 3–5ʺ capacity, 1-1/2ʺ deep
• Low-friction wrinkle band construction with thumbscrew for
precise adjustment
• Used on small aircraft and motorcycle engines where cylinders
are pushed over piston during assembly
®
RC980 Ring Compressor Set (Blue-Point )
RC40C
RCL30 • Works both horizontally and vertically with pliers grip handle
• Fine tooth ratcheting mechanism
• Includes six hardened steel bands: 2-7/8–3-1/8ʺ, 3-1/8–3-3/8ʺ,
3-3/8–3-5/8ʺ, 3-5/8–3-7/8ʺ, 3-7/8–4-1/8ʺ and 4-1/8–4-3/8ʺ
RC980-10 Optional Band (Blue-Point )
®
• 5-1/2–5-3/4ʺ capacity
RC980-11 Replacement Pliers (Blue-Point )
®
RC980-7 Optional Band (Blue-Point )
®
RCW60
• 4-1/2–4-3/4ʺ capacity
®
RC980-8 Optional Band (Blue-Point )
• 4-3/4–5ʺ capacity
RC980-9 Optional Band (Blue-Point )
®
• 5–5-1/4ʺ capacity
®
RC980-9.5 Optional Band (Blue-Point )
• 5-1/4–5-1/2ʺ capacity
RC980
784
