BUSHING/SEAL: INSERTER/REMOVER

A57CA A57-35 SHOP

A57Q
A57Q Bushing Remover/Inserter Set
• For standard and specialized bronze,
steel, rubber or Enlox bushings
• Range of adaptor sizes covers nearly all shackle and A57-3 A57-37 A57-36
steering bushings
• New bushings are inserted by tightening screw, which
forces the bushing into place without hammering
• Sleeve permits forcing out of old bushings
• Useful where limited space prevents driving bushings out
• Five smallest adaptors are used only with the
smallest driver
A57-15
Stock No. Description Stock No. Description
A57CA Screw A57-41 Sleeve Adaptor EQUIPMENT
A57-35 Screw A57-38 Sleeve Adaptor A57-27 A57-16
A57-3 Washer A57-36 Sleeve
A57-37 Sleeve Adaptor A57-27 Puller
A57-39 Sleeve Adaptor
Dimension, Dimension, Dimension,
Dimension,
Stock No. inches small inches large inches large
inches O.D. A57-14A
O.D. I.D. O.D.
A57-15 Bushing Driver
A57-16 .339 .434 — —
A57-17 .430 .497 — — A57-18 A57-8
A57-26 .492 .622 — —
A57-18 — .493 — .559
A57-25 — .554 — .684
A57-14A Bushing Driver
A57-8 .555 .622 — —
A57-19 .601 .668 — —
A57-7 .618 .747 — —
A57-6 .678 .809 — —
A57-5 .728 .856 — — A57-5 A57-11 A57-46
A57-24 .742 .997 — —
A57-10 .789 .918 — —
A57-11 — .851 — .980
A57-22 — .907 — 1.046
A57-12A — .919 — 1.027
A57A13 — .993 — 1.122
A57-46 — 1.034 — 1.136
A57-20 — 1.055 — 1.184
A57-23A — 1.101 — 1.230 A57-20 A57-45 A57-42
A57-45 — 1.250 1.125 —
A57-42 — 1.406 1.187 —
A57-48 1.206 1.500 — —
A57-29 1.222 1.372 — —
A57-40 1.367 1.625 — —
A57-44 — 1.812 1.375 —
A57-43 — — 1.625 2.000
A57-47 — — 1.859 2.000 A57-48
17/32 A57-44
A57-51 — — —
opening
1-3/8
A57-50 — — —
opening
ESD1428 Bearing (1/2ʺ I.D., 1ʺ O.D.)
ME4A2 Nut (1/2ʺ-20)
ME4A4 Nut (5/8ʺ-18)
A57-43 A57-51
