BUSHING/SEAL: DRIVER SETS
EQUIPMENT
Heavy-Duty Metric Bushing Standard Bushing Driver Set
Driver Set A157C Standard Bushing Driver Set
• Adaptors held on drivers with
A261M Metric Bushing Driver Set knurled nut
• Includes an extra large driver • Small and medium drivers
handle and adaptors in (A157-3 and A157-2) fit all smaller
40–80 mm sizes A261M bushings (A157-6–A157-12); large
• Packaged in PB117 storage box driver (A157-1) fits remaining
bushings (A157-13–A157-22)
Stock No. Description • Industrial finish
A257-1 Extra Large Driver Handle • Packaged in PB20 storage box A157C
A257-5 Driver Nut
A261M1 Adaptor (40–44 mm) Stock No. I.D., inches O.D., inches
A261M2 Adaptor (42–45 mm) A157-1 Large Driver Handle 13/16
A261M3 Adaptor (45–48 mm) A157-2 Medium Driver Handle 9/32
A261M4 Adaptor (48–52 mm) A157-3 Small Driver Handle 7/16
A261M5 Adaptor (50–53 mm) A157-4 Driver Nut, 5/16ʺ-24 —
A261M6 Adaptor (55–60 mm) A157-5 Driver Nut, 1/2ʺ-20 —
A261M7 Adaptor (60–65 mm) A157-6 3/8 7/16
A261M8 Adaptor (65–70 mm) A157-22 15/32 17/32
A261M9 Adaptor (70–75 mm) A157-7 7/16 1/2
A261M10 Adaptor (75–80 mm) A157-8 1/2 5/8
PB117 Storage Case A157-9 9/16 11/16
SHOP Heavy-Duty Bushing Driver Sets A157-12 11/16 1-1/16
11/16
5/8
A157-10
5/8
3/4
A157-11
13/16
3/4
7/8
A157-13
A257 Complete Heavy-Duty
13/16
15/16
A157-14
Bushing Driver Set
7/8
1
A157-15
• Complements the A157C set
15/16
A157-16
by adding 27 larger adaptors
1-1/8
1
A157-17
for transmission work as well
as many other automotive and
1-1/8
1-1/4
A157-19
industrial applications
1-3/16
1-5/16
• Industrial finish A257 A157-18 1-1/16 1-3/16
A157-20
• Packaged in PB27 storage box A157-21 1-1/4 1-3/8
PB20 Storage Case
Stock No. I.D., inches O.D., inches
A257-1 — 1-1/8
A157-5 Driver Nut, 1/2ʺ-20 — A158B Heavy-Duty
A257-23 1-5/16 1-7/16 Bushing Driver Set
A257-24 1-3/8 1-1/2 • Includes (8) basic adaptors for
A257-25 1-7/16 1-9/16 servicing bushings on trucks,
A257-26 1-1/2 1-5/8 tractors and buses
A257-27 1-9/16 1-11/16 • Adaptors are secured to
A257-28 1-5/8 1-3/4 threaded driver shaft by
A257-29 1-11/16 1-13/16 knurled nut A158B
A257-30 1-3/4 1-7/8 • Industrial finish
• Packaged in PB34 storage box
A257-31 1-13/16 1-15/16
A257-32 1-7/8 2 Stock No. I.D., inches O.D., inches
A257-33 1-15/16 2-1/16 A257-1 — 1-1/8
A257-34 2 2-1/8 A157-5 Driver Nut, 1/2ʺ-20 —
A257-35 2-1/16 2-3/16 A257-23 1-5/16 1-7/16
A257-36 2-1/8 2-1/4 A257-24 1-3/8 1-1/2
A257-37 2-3/16 2-5/16 A257-25 1-7/16 1-9/16
A257-38 2-1/4 2-3/8 A257-26 1-1/2 1-5/8
A257-39 2-5/16 2-7/16 A257-27 1-9/16 1-11/16
A257-40 2-3/8 2-1/2 A257-28 1-5/8 1-3/4
A257-41 2-7/16 2-9/16 A257-29 1-11/16 1-13/16
A257-42 2-1/2 2-5/8 A257-30 1-3/4 1-7/8
A257-43 2-9/16 2-11/16 PB34 Storage Case
A257-44 2-5/8 2-3/4
A257-45 2-11/16 2-13/16 Seal Driver Set
A257-46 2-3/4 2-7/8
A257-47 2-13/16 2-15/16 A1306-1-1 Bolt and Washer
A257-48 2-7/8 3 • Adaptor mounting
A257-49 2-15/16 3-1/16 Stock No. Description
PB27 Storage Case A1306-1-1 Bolt and Washer
786
Snapon.com 1.877.762.7664
