ENGINE SERVICE: SERVICE TOOLS

Harmonic Damper Pulley Pullers
HDP1800 15 pc Master Harmonic Damper Pulley Puller Set
• Combines (4) harmonic pulley puller kits into one master kit SHOP
• Features three styles of legs including the unique patent-pending,
industry-exclusive side-turn legs
• Includes an extra set of spring washers and a spare clevis pin
• Compact design has everything needed inside a blow-molded case
®
HDP1835 ‡ Harmonic Damper Pulley Puller for Ford /GM ®
• Revolutionary low-profile legs fit smaller narrow pulley pockets and
have the correct geometry to work on a wide range of applications
because the legs grasp on the backside of the spoke
• New design increases the bite of the leg to the pulley as it’s tightened
• Compact design accommodates tight engine compartments
• Spring-loaded legs maintain position to save time as the puller is
positioned on the harmonic damper pulley
• Saves the average user approximately 30-minutes
HDP1740 ‡ Two-Jaw Harmonic Pulley Puller
• Specially designed two-jaw puller for smaller cars with HDP1800
four-spoke pulleys
• Patent-pending side-turn legs quickly and easily grab the pulley
• Compact low profile narrow design fits the small pockets found on
most pulleys EQUIPMENT
• Spring-loaded legs maintain their position and save time as the puller
is positioned on the pulley
HDP1345 ‡ Harmonic Dampener Pulley Puller
• Includes (6) push rods in multiple lengths and special patent
pending tip
• Spring-loaded legs retain leg position and have correct geometry
for Dodge pulleys YA13350
®
• Gives greater ease and control when installing the puller in
confined areas
• Eliminates the time consuming process of removing the radiator
and other components
YA13350 Harmonic Dampener Pulley Puller (Blue-Point )
®
• Use on 3.6L Camaro engines
®
• Unique design accesses the pulley on internal pulley ledges
HDP6490 ‡ Harmonic Damper Pulley Puller
• New spring-loaded legs allow for leg position retention
• Provides greater ease and control when installing the puller in
confined areas
• Removes 3- and 6-spoke harmonic damper pulleys found on many
Chrysler and GM engines
®
®
• Eliminates the need to remove the radiator or other components
YA6010A Harmonic Dampener Pulley Holding Tool (Blue-Point )
®
• Saves time during removal and installation of the crank bolt on most
®
®
engines in Honda and Acura vehicles
• Verify exact model year/engine size coverage with tool instructions
• When used with a 1/2ʺ drive breaker bar or ratchet, prevents the pulley
from rotating when removing/installing the pulley bolt
®
YA9740A-6 Short Push Rod (Blue-Point ) HDP6490
• For older model YA9740 pullers
• For use on crankshafts that are not drilled to full depth
YA6010A

• Do not use “cheater bars” on handles 779
• ‡ These products can expose you to chemicals which are known to the state of California to cause
cancer and reproductive harm. See pages 906-907 for details.
• Read safety precautions on pages W1 to W4
