ENGINE SERVICE: SERVICE TOOLS

Fuel System Maintenance
S6222 Oil Rail Socket
• Designed to aid the removal/installation of the ball/cup from the high-pressure oil rail to SHOP
service the o-rings
®
• Previously only repairable by replacing the entire Ford OEM High-Pressure Oil Manifold
as a unit, now allows manifold rebuilds for a fraction of the cost S6222

CJ113B
S6192A
CJ117C

CJ147A
YA1350
Power Steering/Alternator/Water Pump ADT30KT EQUIPMENT
S6192A Water Pump Socket CJ147A Power Steering Gear Lower Pinion
• 1/2ʺ square drive socket features dovetail design to Bearing Puller
deliver positive engagement when applying high-torque • Required tool to comply with GM recall bulletins
®
• Black industrial finish #02049 and #03062 regarding power steering gear
®
• Applications: 1992–2011 Cadillac Northstar 4.6 L V8; lower pinion bearing separation
®
1997–1998 Oldsmobile Aurora 4.0 L • To correct the problem, inspect the condition of the lower
®
S6192A-1 Water Pump Socket Stabilizing Strap pinion bearing and replace the lower pinion bearing—in
• Bolts on water pump to secure S6192A water a few cases, replacement of the rack and pinion steering
pump socket in place during water pump removal gear assembly may be necessary—instructions included
and replacement with tool
®
®
• Includes (2) M6 x 12 bolts for securing strap to • Applications include Buick : Regal 1996–1998;
®
water pump Chevrolet : Cavalier 1996–1998, Lumina 1997–1998,
®
®
• Black industrial finish Lumina APV 1996, Malibu 1997–1998, Monte Carlo
®
®
®
• Applications: 1992-2011 Cadillac Northstar 4.6 L V8; 1997–1998,Venture 1997–1998; Oldsmobile : Cutlass
®
1997-1998 Oldsmobile Aurora 4.0 L 1997–1998, Cutlass Supreme 1996–1998, Silhouette
®
®
CJ113B Pulley Installer, Power Steering/Alternator 1996–1998, Intrigue 1998; Pontiac : Grand Prix 1996–
®
(for domestic vehicles) 1998, Sunfire 1996–1998, Trans Sport 1996–1998
®
• Designed for US vehicles ADT30KT ‡ Alternator Pulley Kit (Blue-Point )
• 1ʺ pulley driver hex, 7/16ʺ pressure screw hex, thread • Aids installation and removal of Alternator Decoupler
size of 5/8ʺ-18UNF-2A (puller end) and 3/8ʺ 16UNC-2A Pulleys either OWC (one way clutch) or OAD (Overrunning
(shaft end) Alternator Decoupler)
®
• 4-5/8ʺ long • Varying lengths of hex, TORX and spline configurations
CJPS4 Power Steering and Alternator allow user to handle unique combinations for a
difficult task
Installation Adaptor • Master kit eliminates the need to shop around for
• 2.85ʺ Long hard- to-find tools and reduces service bay downtime
CJ117C Power Steering and Alternator Pulley Puller that can erode a technician’s profit
• Includes short adaptor to remove small • One Way Clutch (OWC) Pulleys and Overrunning
®
flange-type pulley; long adaptor is used for GM Alternator Decoupler (OAD) Pulleys exist on over
200-platform vehicles 20 million cars and growing
®
• Can also remove Chrysler alternator pulleys that • Tool can be used on all major ADP Manufacturers
have double grooves including INA , Gates and Litens ®
®
®
• Replace pulleys with CJ113B Installer • The most comprehensive kit on the market
• Long adaptor included to handle pulleys on • Features a combination of hex bits, TORX bits, spline
®
®
GM minivans sockets, and specialty bits to work in conjunction to
• Nickel-chrome finish, industrial-finish screw remove pulleys from alternator
• Designed for most US vehicles (replace pulley with • Drop forged and precision CNC components to meet the
CJ122 sets) tight tolerances of the application
CJ122 2 pc Power Steering Pulley Installer Set YA1350 Toyota Water Pump Pulley Wrench
®
• Includes installer and pulley installer shaft (Blue-Point )
®
• Thread size of 5/8ʺ-18UNF-2A (puller end) and 3/8ʺ • Essential tool for preventing pulley damage when
16UNC-2A (shaft end) removing or installing bolts
CJ124A Power Steering and Alternator Pulley Puller • Fixed pin dimension for quick, easy installation
• This is a larger version of CJ117C • Unique bend to clear engine compartment obstacles
®
®
®
• Designed for Chrysler , Ford and earlier GM vehicles • Wrench head shaped for generous clearance around
the bolts
• Do not use chrome or industrial finish hand tools with impact drivers 775
• ‡ These products can expose you to chemicals which are known to the state of California to cause
cancer and reproductive harm. See pages 906-907 for details.
• Read safety precautions on pages W1 to W4
