ENGINE SERVICE: SERVICE TOOL

Timing/Belt Replacement
YA9680 Camshaft Pulley Tool CCS100PK 4 pc GearLock Single Gear YA9680
®
(Blue-Point ) Clamp Set SHOP
• Designed to hold the camshaft pulley in • Includes (4) CCS100 GearLock Single
place while turning the center shaft bolt Gear Clamps
• Extremely useful on transverse mounted • Used on single and twin cam engines
V6 engines, such as the Nissan when a dual cam gear lock may not fit
®
Maxima /VG30 engine and Toyota • Perfect tool in situations where YA1150
®
®
Camry /3VXFE and 1MZFE engine individual gears need to be locked, such
®
• Rear pulleys on these vehicles are as when gears need to be removed to
located in close proximity to the shock replace seals
tower making it difficult to remove/ • Forcing screw and thread insert are made
replace the center shaft without this tool of steel while the body made from high-
YA1150 Small-Pin Cam Gear Holder strength fiberglass-reinforced polymer
®
(Blue-Point ) MLS500 GearLock Dual Timing
• Small diameter (10 mm) grooved pins Gear Clamp ML6000
fit snugly into the small holes in the • Can be used on most vehicle makes and
cam gear models with timing belts
• Long handle with a cushioned grip • Used for most dual cam engines to
provides excellent leverage so the cam quickly lock and hold valve timing during
gear bolt can be tightened or loosened belt replacement
• Companion tool to YA9680, which has • Patented “Multi-Point” adjustment for EQUIPMENT
larger diameter pins for cam gears with positive fit on all gear diameters
larger holes • Horizontal and vertical adjustments
ML6000 Cam Lock Tool/Timing Gear provide coverage over wide range of
®
Clamp (Blue-Point ) gear diameters

• Prevents engine damage resulting from • Spring-loaded GearLock Dual Timing CC100
incorrect timing Gear Clamp reduces setup time
• Maintain valve timing during belt • Engagement teeth are made of
replacement on twin and quad heat-treated forged steel and frame
cam engines constructed of high-strength
• Compact design allows access in fiberglass-reinforced polymer
transverse engines MLS500KT GearLock Timing Gear
• Fits timing gear diameters from Clamp Kit
approximately 4–6ʺ (101–152 mm) • Can be used on most vehicle makes and
• Fits gear spacing approximately 0.06–3ʺ models with timing belts
(1.6–76 mm) • Quickly locks and holds valve timing
®
CC100 Single Cam Clamp (Blue-Point ) during belt replacement on most
• Single cam clamp can be used on dual-cam engines
engines where the dual clamp ML6000 • Patented “Multi-Point” adjustment for a ML6000COMBO
will not fit positive fit on all gear diameters
• Compact design permits easy operation • Horizontal and vertical adjustments
in confined engine areas provide coverage over a wide range of
• Prevents engine damage resulting from gear diameters
incorrect timing • Spring-loaded GearLock Dual Timing
• Maintains valve timing during belt Gear Clamp reduces setup time
replacement on twin and quad • Engagement teeth are made of heat-
cam engines treated forged steel
• Simple and easy to use • Frame is constructed of high-strength
• Manufactured from high-strength fiberglass-reinforced polymer
industrial polymers which will not YA9730 Timing Belt Tensioner MLS500KT
corrode or damage engine pulleys Compressor (Blue-Point )
®
®
®
ML6000COMBO Cam Clamp Set • For 1995–later Toyota T-100, Tacoma
(Blue-Point ) and 4Runner ®
®
• Includes (4) CC100 Single Cam Clamps • Turn the square compressor tensioner,
and (1) ML6000 Dual Cam Clamp in a then install the locking pin (YA9730-5
storage tray included with YA9730)
CCS100 GearLock Single Gear Clamp CGH1236 Cam Gear Holder
• Used on single and twin cam engines • Tool holds the hex at the gear hub
when a dual cam gear lock may not fit making removal and tightening of the
• Perfect tool in situations where cam gear bolt easy and accurate
individual gears need to be locked, such • Hole at the center of the tool allows a
as when gears need to be removed to socket to be inserted through the tool YA9730
replace seals for removal and replacement of the cam
• Forcing screw and thread insert are made gear bolt
of steel while the body made from high- • Fits a large number of vehicles, 18
strength fiberglass-reinforced polymer different models from 1995–2011
CGH1236
