FLANK DRIVE IMPACT SOCKETS

Extra-Deep, mm 3/4”

A B C D E
24 SIMML242 39.5 38.1 101.6 127 16.5
SIMML242 6-Point Metric Extra-Deep Impact Socket
®
• For removing and installing the head bolts on Cummins ISX engines SIMML242

Shallow/Thin Wall, inches DRIVE

A B C D E
1-1/2 IMFS482A 54 44-2/5 36-3/5 63-1/2 24-1/10
IMFS482A

Deep/Thin Wall, inches

A B C D E
3/4 IMFDL242 1-3/8 1-5/8 4-3/4 5-3/4 1/2
Larger sizes available on special order. IMFDL242 TOOLS
®
IMFDL242 3/4ʺ Drive 12-Point SAE 3/4ʺ Flank Drive Deep Thin Wall Impact Socket
®
• Designed to remove the head bolts on Caterpillar C12, C15, C16 and 3406Es where the
front two and back two head bolts are positioned under the valve covers
®
• Applications on certain Caterpillar head bolts require a thin walled socket of a
certain length
®
• Additional applications include Detroit Diesel main bearing cap bolts and 19 mm
®
head bolts on Mercedes-Benz MBE904/MBE906 EGR engines (2007 and later)
®
• Snap-on impact sockets are heat treated to optimize impact service life with a
lower hardness than hand sockets and are able to withstand repeated cycling loads
of impact wrenches
®
• Snap-on uses a proprietary blend of special alloy socket steel that provides long
life and great strength
®
• Flank Drive wrenching system delivers up to 20% more turning power without
®
slipping or rounding, while exceeding ANSI performance standards
Inverted TORX ®
Stock No. A B C
E24 IMSLE242A 1-5/8 1-5/8 3-3/4
®
IMSLE242A 3/4ʺ Drive E24 Inverted TORX Impact Socket
®
• Applications include removing and installing head bolts on MaxxForce 11 and
13 engines found on D15 International 2010–current IMSLE242A
®
• Manufactured from special alloy steel, precision forged and heat treated
for optimum strength and durability

Double Hex, mm

Stock No. A B C D E
20 SIMDML202 35 38.1 120.6 146 13.9 SIMDML202
