IMPACT ACCESSORIES
TOOLS IM133 Extensions with Pin Hole (1ʺ) 1-1/8 13-1/8

A
Stock No.
B
3
1
IM133
7-1/8
IM63B
1-3/8
IM123
Swivel Universal Joint with Pin Hole (1ʺ) 4-3/16
DRIVE IP83 Adaptors with Pin Hole (1ʺ) B C D
A
B
Stock No.
2-1/2
IP83

Stock No.
A
1-1/2
1
3-1/2
IM35
1
4-1/4
3-1/4
IM53
3/4
2-9/16
1-5/8
1 with Pin Hole
IM72
1
2-3/8
IM124B 1-1/2 3/4 with Pin Hole 2-1/4 2-13/16
IM72
1”
IMR3
IM243P IM243R
1ʺ Drive Locking Rings and Pins
Stock No. Description Use with
IM243P Steel Locking Pin 1ʺ Drive Sockets/Accessories up to 1-3/8ʺ (35 mm)
IM243R Synthetic Rubber Locking Ring 1ʺ Drive Sockets/Accessories up to 1-3/8ʺ (35 mm) Plus IM124 Adaptor
IMR3 Socket Retainer All 1ʺ Drive Sockets/Accessories, All #5 Spline Drive Sockets/Accessories
IM483P Steel Locking Pin All Spline Drive Sockets/Accessories Plus 1ʺ Drive Sockets from 1-7/16ʺ (35 mm)
®
FLANK DRIVE IMPACT SOCKETS
Shallow, mm Set 516IMM
Contains:
A B C D E
27 IMM273 44.5 53.8 27.0 57.2 17.5 •
30 IMM303 47.8 53.8 27.0 57.2 17.5 •
32 IMM323 50.8 53.8 33.3 63.5 19.1 •
33 IMM333 52.3 53.8 33.3 63.5 22.4 •
35 IMM353 53.8 53.8 33.5 63.5 22.4 •
36 IMM363 57.2 57.2 34.3 63.5 22.4 •
38 IMM383 59.7 57.2 40.1 69.9 23.6 •
41 IMM413A 59.9 57.2 39.6 69.9 26.4 •
46 IMM463 69.9 60.5 44.2 76.2 30.0 •
50 IMM503 69.9 60.5 49.3 82.6 31.2 •
55 IMM553 82.6 60.3 46.7 82.6 31.8 •
60 IMM603 88.9 57.2 51.6 88.9 38.1 •
65 IMM653 92.1 60.5 63.8 101.6 45.7 •
IMM503 70 IMM703 95.3 60.5 62.2 101.6 45.7 •
75 IMM753 104.8 60.5 67.1 108.0 51.6 •
80 IMM803 108.7 61.1 65.9 108.7 47.6 •
