SOCKET/RATCHET ACCESSORIES

Extension/Lock Button, Chrome (1ʺ) 1”
Stock No. A B
L63 1-1/4 8

L63

Square Drive Adaptors, Industrial (1ʺ) DRIVE
Stock No. A B C D
GLA72A 3/4 1 1-7/16 2-5/8
GLA124A 1 3/4 1-13/16 2-3/4
ASME /ANSI B107.10
®
®
GLA72A

SPLINE SOCKETS TOOLS

®
Snap-on spline wrenching tools have been developed to service high-tensile
strength spline nuts and bolts widely used on both military and commercial
aircraft. Precise, radial spline teeth engage the fastener teeth over a wider
area to minimize stress, and allow application of high torque to reduce risk of
damage to the fastener or to the tool. Chrome tools comply with Military Spec.
MS-33787 and MIL-W-8982. The unique spline wrenching configuration can
also be used on ordinary 6- and 12-point fasteners with an advantage similar
®
®
to the Snap-on Flank Drive wrenching system.
LES343B
Shallow, Inches, Chrome (1ʺ)
Stock No. A B C D E
#32 1 LES323B 1-29/64 1-55/64 1-35/64 2-7/16 53/64
#34 1-1/16 LES343B 1-17/32 1-27/32 1-3/8 2-17/32 7/8
#38 1-3/16 LES383B 1-11/16 1-31/32 1-5/8 2-25/32 1-5/32

HEX BIT SOCKETS

Hex/Standard, inches, Industrial (1ʺ)

Stock No. A B
7/8 IMA283 5-5/8 IMA283-2
1 IMA323 5-5/8 IMA323-2

IMA283

263
• Do not use “cheater bars” on handles
• Do not use chrome or industrial finish hand tools with impact drivers
• Read safety precautions on pages W1 to W4
