FLANK DRIVE IMPACT SOCKETS
®

Deep, mm 1”

A B C D E
30 SIMM303 46.0 53.7 46.0 76.2 19.1
32 SIMM323 52.3 53.7 76.2 82.6 22.4
33 SIMM333 52.3 53.7 53.3 82.5 22.4
38 SIMM383 60.3 57.2 59.7 88.9 25.4 SIMM323
70 SIMM703 97.61 60.45 95.45 127 43.69 DRIVE

Shallow Thin Wall, mm

A B C D E
50 IMM503TW 65 57.2 49 82.6 34.8
55 IMM553TW 75.9 60.5 53.8 88.9 34.8
70 IMM705TW 91.2 82.6 67.5 114.3 44.3 IMM503TW IMM705TW TOOLS

SPECIAL APPLICATION IMPACT SOCKETS

IM724 IM740
Single Square/Shallow, inches Double Square/Shallow, inches

A B C D E A B C D E
3/4 IM724 1-15/16 2-1/8 31/32 2-1/8 21/32 1-1/4 IM740 2-3/8 2-3/8 1-1/8 2-3/8 13/16
13/16 IM726 1-15/16 2-1/8 31/32 2-1/8 21/32
7/8 IM728 2-1/16 2-1/8 31/32 2-1/8 21/32
15/16 IM730 2-1/16 2-1/8 15/16 2-1/8 5/8
1 IM732 2-1/8 2-1/8 1-3/32 2-1/4 25/32
1-1/8 IM736 2-1/4 2-1/4 1-3/32 2-1/4 25/32

1-1/2" DRIVE HANDLES

Sliding T-Handle, Industial (1-1/2ʺ)

Sliding Head Only
Stock No. C A Handle Stock No.
Stock No.
L55 36 L55-2 2-7/8 L55-1
L55
