POWERED TORQUE TOOLS

PNEUTORQUE® PTS™ REMOTE SERIES

17

Remote control versions have no direction control on the tool but
rely on external pneumatic circuitry to provide this function. This
opens up numerous application possibilities for the PneuTorque®
ranging from simple stall shut-off in a hazardous working
environment to sophisticated, multi-spindle torque and angle shut-
off systems.
• Designed to offer excellent power-to-weight ratio
• ±3% repeatability of reading from 20% to 100% of range
• Replaceable square drive

11 PTS REMOTE SERIES NOTE: For full versatility, PTS™ Remotes are supplied without reaction see
pages 79 - 84 for options or discuss bespoke engineered options
180271.B06 3 ∕ 4" sq. dr., 100 - 500 N·m, 74 - 370 lbf·ft with Norbar�
180272.B06 3 ∕ 4" sq. dr., 160 - 800 N·m, 118 - 590 lbf·ft
180273.B06 3 ∕ 4" sq. dr., 200 - 1,000 N·m, 147 - 738 lbf·ft 11 PTS REMOTE SERIES - AUTO TWO SPEED
180274.B08 1" sq. dr., 270 - 1,350 N·m, 200 - 1,000 lbf·ft 180789 3 ∕ 4" sq. dr., 200 - 1,000 N·m, 147 - 738 lbf·ft
180275.B08 1" sq. dr., 400 - 2,000 N·m, 295 - 1,475 lbf·ft 180790 1" sq. dr., 270 - 1,350 N·m, 200 - 1,000 lbf·ft
180276.B08 1" sq. dr., 540 - 2,700 N·m, 398 - 1,991 lbf·ft 180792 1" sq. dr., 540 - 2,700 N·m, 398 - 1,991 lbf·ft
180295.B08 1" sq. dr., 800 - 4,000 N·m, 590 - 2,950 lbf·ft 180793 1" sq. dr., 800 - 4,000 N·m, 590 - 2,950 lbf·ft
1
180279.B12 1 ∕ 2" sq. dr., 1,400 - 7,000 N·m, 1,030 - 5,200 lbf·ft 180796 1 ∕ 2" sq. dr., 1,400 - 7,000 N·m, 1,030 - 5,200 lbf·ft
1
PTS REMOTE PTS REMOTE PTS REMOTE PTS REMOTE PTS REMOTE PTS REMOTE PTS REMOTE PTS REMOTE
Model
52-500 52-800 72-1000 72-1350 72-2000 80-2700 92-4000 119-7000
Part Number 180271�B06 180272�B06 180273�B06 180274�B08 180275.B08 180276�B08 180295.B08 180279�B12
Output Speed (rpm) 27�8 20�1 16 11.5 7�2 5.7 4�1 2
ØD max. 52 52 72 72 72 80 92 119
H1 29 29 29 29 29 29 29 29
Dimensions
(mm) H2 78 78 78 78 78 78 78 78
L 284 284 311 311 344 311 362 385
W 70 70 70 70 70 70 70 70
Tool Weight (kg) 4�1 4�1 6�1 6�1 6.5 6�1 8�9 12�4

PTS REMOTE PTS REMOTE PTS REMOTE PTS REMOTE PTS REMOTE
Model 72-1000 72-1350 80-2700 92-4000 119-7000
Auto Two Speed Auto Two Speed Auto Two Speed Auto Two Speed Auto Two Speed
Part Number 180789 180790 180792 180793 180796
Output Speed (rpm) 78 56 22 20 10
ØD max. 72 72 80 92 119
H1 29 29 29 29 29
Dimensions
(mm) H2 78 78 78 78 78
L 330 330 344 395 422
W 70 70 70 70 70
Tool Weight (kg) 6�2 6�2 7�0 9�3 12�78

enquiry@norbar�com | www�norbar�com 70
