POWERED TORQUE TOOLS

PNEUTORQUE® PTM SERIES

19

Using twin motor technology, the PTM series of PneuTorques is
engineered to be amongst the lightest and fastest on the market. For
example, the 800 N·m version has a gearbox diameter of just
52 mm, allowing excellent bolt access, and has a maximum free
running speed of 224 rpm. Torque control is normally achieved by
adjustment of air pressure. An air pressure versus torque graph and a
calibration certificate is supplied with each tool.

• Exceptionally compact 52, 72 and 80 mm gearboxes result in light,
well balanced tools
• Fitted with a light robust aluminium reaction plate as standard
• Other reaction plates are available for maximum versatility

• Quiet - less than 83 dB(A) when free running
• Fast operation for rapid bolt run-down
• ±5% repeatability of reading from 20% to 100% of range

11 PTM-52 SERIES - STALL TOOLS - BI-DIRECTIONAL
18100.B06 3 ∕ 4" sq. dr., 100 - 500 N�m, 74 - 370 lbf�ft
18101.B06 3 ∕ 4" sq. dr., 160 - 800 N�m, 118 - 590 lbf�ft
Stall tools are also available as forward only tools, replace B with F when
ordering�

8 ACCESSORIES
18545 1" square drive for PTM-52 The PTM-80, PTM-92 and PTM-119 tools bring the speed advantage
of the twin motor handle to higher capacity PneuTorque® models.
These models deliver an ideal balance between robustness, speed and
weight.

11 PTM-80 SERIES - STALL TOOLS -
BI-DIRECTIONAL
180296.B08 1" sq. dr., 540 - 2,700 N�m, 400 - 2,000 lbf�ft
Also available as forward only tools, replace B with F when ordering.

11 PTM-92 SERIES - STALL TOOLS -
BI-DIRECTIONAL
18159.B08 1" sq. dr., 800 - 4,000 N�m, 590 - 2,950 lbf�ft
18159.B12 1 ∕ 2" sq. dr., 800 - 4,000 N�m, 590 - 2,950 lbf�ft
1
Also available as forward only tools, replace B with F when ordering.
11 PTM-119 SERIES - STALL TOOLS -
11 PTM-72 SERIES - STALL TOOLS - BI-DIRECTIONAL BI-DIRECTIONAL
18102.B06 3 ∕ 4" sq. dr., 200 - 1,000 N�m, 147 - 738 lbf�ft 18108.B12 1 ∕ 2" sq. dr., 900 - 4,500 N�m, 660 - 3,300 lbf�ft
1
18103.B08 1" sq. dr., 270 - 1,350 N�m, 200 - 1,000 lbf�ft 18109.B12 1 ∕ 2" sq. dr., 1,200 - 6,000 N�m, 885 - 4,425 lbf�ft
1
18104.B08 1" sq. dr., 400 - 2,000 N�m, 295 - 1,475 lbf�ft Also available as forward only tools, replace B with F when ordering.
Stall tools are also available as forward only tools, replace B with F when
ordering�

71 enquiry@norbar�com | www�norbar�com
