Mar4D | Cylinder Coordinate Measuring Machines

Mar4D PLQ 4200: Fast and precise

measurement during production

The cylinder coordinate measuring machines from the Mar4D PLQ 4200 product line measure
rotationally symmetrical workpieces with more flexibility and more conveniently than ever before.
They operate at the highest speed and level of precision providing fast and reliable measuring results.

With the Mar4D PLQ 4200, Mahr provides its customers with a high-performance measurement solution
for complex rotationally symmetrical workpieces. The multisensor system covers a particularly broad
range of dimensional measuring tasks. The new machine also has a particularly sturdy design enabling 3D
measurements to be completed directly during production, as well as offering shorter processing times
and thus increased throughput and excellent productivity rates.

+ Advantages

• Future-proof thanks to combined measuring technology: optical and tactile solution in one machine
• Versatile: Check several features such as the length, diameter, form, position, contour, roundness, roughness,
or 3D geometries, such as the symmetry, during a single measuring run
• Fast and precise: Unique speed and optimum axis accuracy even as the tolerances become smaller achieved
thanks to specially developed control architecture
• Flexible for workpieces with a diameter up to 200 mm, a length of up to 1000 mm. and a weight of up to 50 kg
• Ergonomic operation and unique safety concept
