MaraMeter 840 FG

Indicating Snap Gage

ACCESSORIES
Order no. Product name Product
type

4333000 Millimess 5 µm, ± 130 µm 1004
4334000 Millimess 1 µm, ± 50 µm 1003
4334001 Millimess 2 µm, ± 130 µm 1003 XL
1004
4335000 Millimess 0.5 µm, ± 25 µm 1002
4337620 Digital indicator, 0.0005 mm, 12.5 mm 1086 R
4337624 Digital indicator, 0.0005 mm, 12.5 mm 1086 Ri
4450051 Holder, frame size 2 840 Fk/2
4450020 Base, for stationary application 840 Ff
4360002 Standard contact point, carbide, r = 1.5 mm 901 H
4360041 Spherical contact point, carbide, l = 10 mm, r = 6 mm 902 H
4360043 Spherical contact point, carbide, l = 15 mm, r = 6 mm 902 H
1003 4360044 Spherical contact point, carbide, l = 20 mm, r = 6 mm 902 H
4360101 Flat contact point, carbide, l = 6 mm 903 H
4360103 Flat contact point, carbide, l = 10 mm 903 H
4360105 Flat contact point, carbide, l = 15 mm 903 H
4360106 Flat contact point, carbide, l = 20 mm 903 H
4360131 Conical contact point, carbide, r = 0.3 mm 904 H
4360150 Ball contact points, carbide, l = 8.5 mm, d = 1.0 mm 906 H
4360151 Ball contact points, carbide, l = 8.5 mm, d = 1.25 mm 906 H
1002
4360152 Ball contact points, carbide, l = 8.5 mm, d = 1.5 mm 906 H
4360153 Ball contact points, carbide, l = 8.5 mm, d = 1.75 mm 906 H
4360154 Ball contact points, carbide, l = 8.5 mm, d = 2.0 mm 906 H
4360155 Ball contact points, carbide, l = 8.5 mm, d = 2.5 mm 906 H
4360156 Ball contact points, carbide, l = 8.5 mm, d = 3.0 mm 906 H
4360157 Ball contact points, carbide, l = 8.5 mm, d = 3.5 mm 906 H
4360158 Ball contact points, carbide, l = 8.5 mm, d = 4.0 mm 906 H
4360159 Ball contact points, carbide, l = 8.5 mm, d = 4.5 mm 906 H
1086 R;
1086 R-HR; 4360160 Ball contact points, carbide, l = 9 mm, d = 5.0 mm 906 H
1086 ZR 4360161 Ball contact points, carbide, l = 9 mm, d = 5.5 mm 906 H
4360162 Ball contact points, carbide, l = 9 mm, d = 6 mm 906 H
4360163 Ball contact points, carbide, l = 9 mm, d = 6.35 mm 906 H
4360164 Ball contact points, carbide, l = 10 mm, d = 6.5 mm 906 H
4360165 Ball contact points, carbide, l = 10 mm, d = 7 mm 906 H
4360166 Ball contact points, carbide, l = 11 mm, d = 7.5 mm 906 H
4360167 Ball contact points, carbide, l = 11 mm, d = 8.0 mm 906 H
4360168 Ball contact points, carbide, l = 12 mm, d = 8.5 mm 906 H
1086 Ri 4360169 Ball contact points, carbide, l = 12 mm, d = 9.0 mm 906 H
4360170 Ball contact points, carbide, l = 13 mm, d = 10.0 mm 906 H
4360200 Flat contact plates, steel, measuring surface ø 11.3 mm 907
4360201 Flat contact plates, carbide, measuring surface ø 7 mm 907 H
4360210 Spherical contact plates, steel, steel, measuring surface ø 12 mm 908
4360211 Spherical contact plates, steel, carbide, measuring surface ø 12 mm 908 H
4360240 Pin contact point, carbide, l = 2 mm, measuring surface ø 1 mm 911 H1
4450052 Holder, frame size 3 840 Fk/3

M 2,5 M 2, 5 M 2,5 M 2,5 M 2,5

5
5 M 2,5 M 2,5
10 30°
6 l l
l R30
R 1,5 R 6 ø4 R 0,3 5 5
ø4,2 ø4, 2 ø4,2 ø4 d ø11,3 ø12
901; 901 H; 902; 902 H 903; 903 H 904; 904 H 906 H 907 908 H 911 H1
