Millimar 832 PE/F1 / 832 PE/F2

Compact Length Measuring Instrument

FEATURES

• Digital and analog display
in one unit
• Large, high contrast digital
display of the exact deviation
from zero
• Analog display of measurement
related information
• With its fixed ratio and con-
trolled compressed air supply,
the digital Dimensionair is a
sturdy, reliable system for
manufacturing environments
• Only one standard needed for
zero offset; the instrument is TECHNICAL DATA
precalibrated for the correct ratio
• Measuring ranges and resolu- Order no. 2004100 2004112 2004106 2004118 2004103 2004115 2004109 2004121
tions for almost all measuring Product type 832 PE/F1 832 PE/F2 832 PE/F1 832 PE/F2
applications (including measur- Magnification 1260:1, 2500:1, 5000:1 10000:1, 20000:1
ing equipment with 2, 3, 4 and Tooling ID 60, 50, 20 10, 5
6 nozzles, air sensors and nozzle Inputs for 1 2 1 2
measuring probes, etc.) pneumatic
• Suitable for dynamic measuring
measurement equipment
• RS-232 output for communica- Number of 1-3
tion with a data storage device, jets
computer or printer, for Range of µm ± 80, ± 40, ± 20 ± 8, ± 4
statistical process control digital display
• Master deviation – improved Range of inch ± .003“, ± .0015“, ± .00075“ ± .0003“, ± .00015“
measurement with even more digital display
accurate automatic zero offset Resolution µm 0.2 0.1
• Package contains: power Resolution inch .00001“ .000005“
source, supply hose AHO-2, Graduation µm 4, 2, 1 0.4, 0.2
adapter for pneumatic plug value
gages, Federal compatible Graduation inch 150 µ“, 75 µ“, 38 µ“ 15 µ“, 8 µ“
value
Display Display mode A (or A and B for 2 channel models only)
Tolerance 5 LEDs
display
Compatibility Federal
Dynamic Max, Min, Max-Min
functions
Statistical Actual value, nominal value
functions
Response time s 0.43
digital display
Response time Approx. 1 s (depending on the hose length of the measuring equipment)
(Air)
Error limit +/– 1 digit
Repeatability ±1 digit or ±1% of the indication range (whichever is greater)
[µm]
Data interface RS232C
Control 5 TTL optocoupler outputs
outputs
Analog output ±5 VDC at maximum amplitude of the selected measuring range for signal ±A, ±B
Energy supply 110 V / 60 230 V / 50 110 V / 60 230 V / 50 110 V / 60 230 V / 50 110 V / 60 230 V / 50
Hz, Power Hz, Power Hz, Power Hz, Power Hz, Power Hz, Power Hz, Power Hz, Power
source source source source source source source source

Order no. Depth Depth Height Height Width Width
mm inch mm inch mm inch
2004100 254 10“ 197 7.75“ 216 10.25“
2004112 254 10“ 197 7.75“ 216 10.25“
2004106 254 10“ 197 7.75“ 216 10.25“
2004118 254 10“ 197 7.75“ 216 10.25“
2004103 254 10“ 197 7.75“ 216 10.25“
2004115 254 10“ 197 7.75“ 216 10.25“
2004109 254 10“ 197 7.75“ 216 10.25“
2004121 254 10“ 197 7.75“ 216 10.25“
296 Millimar | Electrical Length Measuring Instruments
