Page 629 - 蓝带金统立KINGTONY2025年样本

UNDERCAR SERIES

Oil Pressure Tester Kit

9DP3201
• Suitable for testing engine oil pressure and transmission pressure
• Applicable to both gasoline and diesel engines, also suitable for 13
passenger cars and light trucks PC.
• Gauge reading range from 0-150 PSI (0-10 bar)
• Provided with an oil filter clamp for piercing through oil filter
canister when oil pressure switch is hard to access

kg 2.10 1 / 5
Adapter
Black Silver
(Imperial threads) (Metric threads)
1/2” x 20 UNF M10 x P1.0
3/8” x 20 UNF M12 x P1.5
1/4” x 18 NPTF M14 x P1.5
1/8” x 27 UPT M16 x P1.5
R 1/8” DIN M18 x P1.5

Universal Terminal Release Tool Set

9DT11
• Suitable for most of the vehicles, VW Group,
BMW, Opel, Renault, Ford, Daimlerchrysler, Fiat,
Toyota and Saab g 850 1 / 10 12
• Use to loose contacts easily or carry out other
applications in the field of car electricity PC.

A 9DT11-1 ABS 4.0mm round terminal
B 9DT11-2 3.5mm round terminal
C 9DT11-3 1.5mm round terminal
D 9DT11-4 Maxi power timer
E 9DT11-5 Pit pod / Faston 6.3mm
F 9DT11-6 JPT / SPT
G 9DT11-7 Micro timer ii
H 9DT11-8 Standard tool
I 9DT11-9 Standard 2.72mm
J 9DT11-10 Standard 1.48mm
K 9DT11-11 Standard 1.89mm
L 9DT11-12 Micro standard
Safety Goggles

9CK-101
• Soft PVC frame & lens high impact clear polycarbonate
• Anti-dust and anti-impact vents
L2
L1
KT NO. inch mm inch mm g
9CK-101 2-7/8 74 6 153 70 20 / 200

Steel Wire Brush

9CZ101
• Material : wood handle / steel wire
• Wire brush with three rows L2
L2
L1
H
KT NO. mm mm mm g H
9CZ101 22 258 105 65 24 / 144 L1
588
