UNDERCAR SERIES

Battery Tester Anti-freeze &

9DD21 Coolant Tester
9DD22
• Test battery hydrometer quickly
• Use to check battery condition and charge state • Use to check condition of antifreeze and coolant
• Detects hot or cold overcharge accurately (Ethylene Glycol)
• For 6 / 12 / 24 volt system • Ideal for avoiding winter freeze-ups and summer
g 85 10 / 100 overheating
g 85 10 / 100

Mechanic's Stethoscope

9DH11
• Ears covered with plastic, effective to separate from
outside noise
• 210mm extension probe can expand the space while
operating or using in narrow space
• Quickly to find and detect the abnormal noise with the
probe
• Use for detecting various vehicles parts or machine
equipment
g 147 12 / 72

Vehicle Battery Tester

9DC51

• Test a 12V lead-acid battery of any vehicle
• CCA testing(SAE/DIN/EN/IEC/CA standard)-Working voltage: DC 9~15V
• Engine starting voltage test - Measures the minimum voltage when the engine starts
• Charging voltage test - About 14 volts
• CCA Level bar indication - LOW / MID / HIGH
• LCD with background light

KT NO. Test range(V) Size(mm) g
L x W x H
9DC51 9 ~ 15 135 x 78 x 33 374 1 / 30

Digital Glow Plug Tester

9DM1A1

• Suitable for steel and ceramic glow plugs
• LCD Display
• Short circuit protection & reverse charging protection
• Auto power off : 110 seconds
• 9V batteryx1 (Battery not included)
• CE approval

KT NO. Glow plug(V) Size(mm) g
L x W x H
9DM1A1 3.5-4.4-5-7-8.5 135 x 78 x 33 356 1 / 40
10-11-24

586
