Air Hose Reel

7991

• Automatic rewind with SK5 alloy steel spring
• 16 teeth gear-stop ensures safety
• 300 psi working pressure allowed
• Sturdy structure with 0.7mm thick steel rail stored in iron case
• Replaceable air house design & hanging rack

• Pull the air hose to • Install new air • Dismantle connection
the end till it shows hose
joint replacement
CAUTION
Do not pull the air hose
when seeing tag

16 teeth gear design can spread stress
evenly and stop returning
1 Bar = 1.01972 kgf/cm 2
1 Bar = 14.5036 psi

Working
KT NO. Hose I.D. Hose O.D. Hose length Type Air lnlet / outlet pressure psi kg
inch
(M)
mm
mm
79910-10 8 12 10 Asian 1/4"BSPT 300 5.5 1 / 2
79910-15 8 12 15 Asian 1/4"BSPT 300 6.5 1 / 2
79911-10 8 12 10 US 1/4"NPT 300 5.5 1 / 2
79911-15 8 12 15 US 1/4"NPT 300 6.5 1 / 2
79912-10 8 12 10 EU 1/4"BSPT 300 5.5 1 / 2
79912-15 8 12 15 EU 1/4"BSPT 300 6.5 1 / 2

Air Lubricator

799A

• Semi auto drain valve
• Steel guards offer better protection Regulator
• Easy installation and disassembly
Lubricator
160mm
OUT
IN
Air Ouput
Air Input

231.3mm

157mm Filter

Drain valve

Filter Max Input Max Output Max Operation Drain Oil Weight
Port Size Air Inlet
KT NO. Element Pressure Pressure Flow Temperature Range Capacity Capactity (Kgs)
(inch) ˚ (inch)
(μ) (psi) (psi) (L/min) ( C) (ml) (ml) (Ibs)
799A0-23C 1/4" 5 215 7~150 1750 5 ~ 60 80 150 1/4"BSPT 1.40 3.17 1 / 12
799A1-23C 1/4" 5 215 7~150 1750 5 ~ 60 80 150 1/4"NPT 1.42 3.17 1 / 12
799A0-33C 3/8" 5 215 7~150 2500 5 ~ 60 80 150 3/8"BSPT 1.14 2.51 1 / 12
799A1-33C 3/8" 5 215 7~150 2500 5 ~ 60 80 150 3/8"NPT 1.14 2.51 1 / 12
1/2"
799A0-43C 1/2" 5 215 7~150 3000 5 ~ 60 80 150 BSPT / NPT 1.15 2.53 1 / 12
