PNEUMATIC TOOLS

3-In-1 Inflator

9BM
• Diaphragm pressure gauge
• Accuracy: ANSI B40.100 ±3% ~ ±2% ~ ±3%
• Special rubber housing protects manometer against light impacts
• 3 functions(check, release, inflator) all together on the press handle
• Variable trigger, two control positions for inflate/deflate level 9BM2110
• Flexible 400MM high pressure rubber hose with clip-on air tire chuck 9BM2111
9BM2210
• Pressure Range: 9BM2211
0-160 psi (9BM21) / 0-220 psi (9BM22)
• Built in hang-up hook allows easy storage

9BM2110A
Inflator
Release 9BM2111A
Check
146
20 185
9BM2-01 9BM2-02
L1

L2
Air Inlet
L (mm)
KT NO. Pressure range (BSPT/NPT) L1 L2 Air hose g
(psi)
(ID)
9BM2110 160 1/4"BSPT Ø13 x 400 180 3/8" 500 1 / 12
9BM2111 160 1/4"NPT Ø13 x 400 180 3/8" 500 1 / 12
9BM2210 220 1/4"BSPT Ø13 x 400 180 3/8" 520 1 / 12
9BM2211 220 1/4"NPT Ø13 x 400 180 3/8" 520 1 / 12
9BM2210A 220 1/4"BSPT Ø13 x 400 180 3/8" 600 1 / 12
9BM2211A 220 1/4"NPT Ø13 x 400 180 3/8" 600 1 / 12
9BM2-01 (included in all 9BM series) 20 - 25 -
9BM2-02 (included in 9BM2210A & 11A only) 185 - 105 -

PU Air Spiral Hose

79953 79962
• Super mechanical strength and excellent abrasive resistance
• Superior heat and cold resistance
• Oil resistance
• Light weight
• Temperature resistance from -20 C ~ +60 C
˚
˚

79953 79962

Weight
KT NO. Hose I.D. Hose O.D. Hose Length Working Pressure Maximum Pressure Type Male PT Fitting (kgs) (lbs)
(inch)
(psi) (bar)
(psi) (bar)
(M)
(mm)
(mm)
79953-10 8 12 10 108 7.4 320 22.2 - 1/4"BSPT 0.80 1.76 1 / 20
79953-15 8 12 15 108 7.4 320 22.2 - 1/4"BSPT 1.30 2.87 1 / 12
79962-10 8 12 10 160 11.0 640 44.1 EU 1/4"BSPT 0.92 2.02 1 / 20
79962-15 8 12 15 160 11.0 640 44.1 EU 1/4"BSPT 1.31 2.87 1 / 12
79962-20 8 12 20 160 11.0 640 44.1 EU 1/4"BSPT 1.63 3.78 1 / 10
276
