Rear Wheel Socket Impact Bit Socket

8534M 1" 1954 809622M 1"
• 4 points • Hex bit & bit holder
• DIN 3121 • DIN 3121

D1 D2

l L
1954 809622M

38
S L 22
ℓ
L
D1
D2
KT NO. SQ mm mm mm mm g 22 L
853417M 17 38.0 54 23.5 76 658 1 / 24
S
L
853419M 19 43.0 54 23.5 76 717 1 / 24 KT NO. mm mm Max. torq g
N‧m
853421M 21 47.0 54 23.5 76 773 1 / 24 195419H H19 54.5 1577 140 12 / 120
8545M 1" 195422H H22 54.5 2436 162 12 / 120
195424H
H24
54.5
2436
176
10 / 100
195427H H27 54.5 2436 200 10 / 100
• DIN 3121 195430H H30 54.5 2436 232 6 / 60
• 17SQ x35MM Isuzu, Mitsubishi, Nissan, Mazda 195432H H32 54.5 2436 243 6 / 60
• 19SQ x41MM Mazda
• 20SQ x38MM Hino, Toyota, Daihatsu 809622M 22 58.0 - 547 1 / 24
• 20SQ x41MM Hino, Toyota, Daihatsu
• 21SQ x41MM Scania, Isuzu, Hino, Mitsubishi, Nissan 809622MxxH 1"
• Hexagon head
• DIN 3121
S
L

L
S
D1 D2 KT NO. mm mm (mm) Max. torq g
N‧m
809622M19H H19 22 93 1577 896 1 / 10
ℓ L Use for
809622M22H H22 22 93 2436 918 1 / 10
809622M24H H24 22 93 2436 932 1 / 10
Outer Wheel Inner Wheel
809622M27H H27 22 93 2436 956 1 / 10
809622M30H H30 22 93 2436 988 1 / 10
809622M32H H32 22 93 2436 999 1 / 10
8015M
Socket Socket
Outer Nut Hub
Inner Nut
The wheel nut socket fits onto both outer nut and inner nut

D1
D2
L
ℓ
KT NO. SQ mm mm mm mm mm g L
85451735M 17 x 35 54 54 13 83 857 1 / 24 L
85451941M 19 x 41 55 54 14 87 924 1 / 24 KT NO. mm mm g
85452038M 20 x 38 58 54 14 83 796 1 / 24 801521M H21 80 710 1 / 24
85452041M 20 x 41 58 54 14 87 1086 1 / 24
85452141M 21 x 41 58 54 14 87 1017 1 / 24 801522M H22 80 720 1 / 24
801524M H24 80 741 1 / 24
801527M H27 80 776 1 / 24
801530M H30 80 820 1 / 24
801532M H32 80 851 1 / 24
801536M H36 80 921 1 / 24
