Specialty Tools Specialty Tools

Engine – Fuel System / Fuel Injection Engine – Fuel System / Fuel Injection

4561 Injection pump wrench 4501 Fuel line pliers

Made in Germany ß r Made in Germany ß
• Application: Operating fastening screws (Ä 13 mm) at the injection • Application: Operation of the quick-release covers with
pump, when replacing the toothed belt or adjusting the injection start light pressure on the fuel line as well as tank aeration
• One-sided box-end wrench • On FIAT/ALFA/LANCIA vehicles with 1.3 l – 1.9 l – 2.4 l diesel,
G • On 1.6 l 4-cylinder diesel engine AUDI, VW Golf, Jetta, Caddy, Passat, CITROËN CHRYSLER ∙ RENAULT
OPEL/VAUXHALL (diesel): Vectra C/Signum 1.9 l diesel ∙ Astra H 1.3 l and 1.9 l ∙
• Surface: chrome-plated
Corsa C / Combo / Meriva 1.3 l
OPEL/VAUXHALL (petrol): Corsa C ∙ Astra G ∙ Vectra C
• Plastic handle

F 1 S K 4

4561 13 165 021925

4561 Turbo charger wrench

Made in Germany ß r
• One-sided box-end wrench for operating the fitting 1 4
D • Problem: Very special screw connection that is not within reach of normal K
tools. Solution: This special curved box-end wrench allows the operation 4501-1 155 058624
of the lower screw connection of particulate filters on turbo chargers
• For: AUDI A4 (B5 ∙ B6 ∙ B7 ∙ B8) ∙ A6 (C5 ∙ C6 ∙ C8) 4590 Flexible hose clamp
VW Passat (3B ∙ 3BG ∙ B6) with 1.9 l and 2.0 l pump
injector engine and particulate filter
• Also for holding the screw connections at the y-pipe on VW/AUDI Ä 12 mm • Clamping flexible hoses ßG
• Surface: chrome-plated
• Firm fixation with clamp ring
R • Made of high-quality plastic

C 1 S K 4
4561-12 12 165 190485

4501 Fuel line pliers 1 K 4
• For heating and fuel hoses
Made in Germany ß up to 15 mm x
• Simple operation of quick-release catches 4590-1 150 021932
O • Application: For use when replacing the fuel filter • For hoses up to 30 mm x 180 021949
4590-2
or performing repair work on the engine
• For e.g. MERCEDES-BENZ ∙ VW-AUDI ∙
FIAT ∙ OPEL/VAUXHALL ∙ CITROËN • For e.g. cooling liquid hoses up to 60 mm x 055753
253
4590-3
• Volvo D13 ∙ D16 ∙ MAN D3876 LF ∙ D1556 LF ∙
D2676 LF and SCANIA engines
• CLAAS agricultural machinery with MAN engine 4590 Flexible hose clamp set
• AdBlue lines and AdBlue injection nozzle
• Straight design • Clamping flexible hoses
• Ergonomically shaped HAZET 2-component ßG
plastic handle covers (blue/black)
A

U

1 K 4 1 è 4
4501-2 235 203499 4590/3 3 058266
394 Valid until December 31, 2021 Components and spare parts from page 482 to 490
