Specialty Tools

Engine – Fuel System / Fuel Injection

4798 Mechanical hydraulic cylinder 12 tonnes 4798 Injector removal tool MERCEDES-
BENZ ∙ Bosch / Delphi
• Cost-effective, since no hydraulic pump is required Jß • Huge amount of time saving since the engine does not have to be Jß
removed to disassemble the injectors
• Very low installation height of just 45 mm
• Spindle nuts M 10 ∙ M 12 ∙ M 14 ∙ M 16 ∙ M 18 included in set • Application: The 12 tonne hydraulic cylinder enables G
• Anti-slip handle simplified operation of very tight injectors
• Aluminium cylinder with low weight • For MERCEDES-BENZ 2.1 l ∙ 2.2 l ∙ 3.0 l V6 (CDI 2.1 l ∙ 2.2 l
• Stroke: 8 mm Delphi ∙ CDI 3.0 l V6 Bosch) ∙ Vito ∙ CLK ∙ Sprinter ∙ Viano ∙ Vario as well
as M ∙ GL ∙ C ∙ GLK ∙ E ∙ CLS ∙ S ∙ R ∙ G-Class ∙ CHRYSLER 3.0 l V6
• Shear pin on the spindle drive protects against overload • Operation of hydraulic cylinders using e.g. HAZET 600 N-19
• Use with universal injector removal tool set HAZET 4798-5/25. • SmartCase (1/3) 165-L
• Operation with combination wrench, e.g. HAZET 600 N-19 • Safety-Insert-System, 2-component soft foam insert.
• SmartCase (1/3) 165-L Insert also suitable for HAZET Assistent
• Safety-Insert-System, 2-component soft foam insert.
Insert also suitable for HAZET Assistent
F

D

R

1 L x W x H è 4 1 L x W x H è 4 C
mm
mm
4798-9/6 355 x 235 x 65 9 210732 4798-8/8 355 x 235 x 65 8 210749
4798 Hydraulic cylinder 20 tonnes

• Application: For very tight injectors Jß
• Working pressure: 700 bar
• Weight: 3.04 kg
• Stroke: 8 mm O
• Dimensions: 100 x 60 mm
• Use with hydraulic foot pump,
e.g. HAZET 4932N-100 and
HAZET 4798-5/25

A

U

1 4
4798-20 210718

Components and spare parts from page 482 to 490 Valid until December 31, 2021 399
