Specialty Tools Specialty Tools

Engine – Fuel System / Fuel Injection Engine – Fuel System / Fuel Injection

4798 Universal injector extraction tool set 4798 Universal injector tool set, Denso

• Enables the removal of the injectors without removing Jß • Enables the removal of the injectors without removing the Jß
the electrical connector or injector head electrical connector or injector head
• Advantage: without any previous injector defect, reinstallation is possible
without recalibration • Application: For Denso injectors: 23670 → 30080 ∙
MB416600 → MB40A ∙ 5870 → 13H50B ∙ 11L 12182 ∙
G • Application: Removal of diesel injectors on the brands Bosch, • Installed on e.g. TOYOTA ∙ NISSAN ∙ MAZDA ∙
23670 → 26011 ∙ 23670 → 0R050 ∙ 10J 06798
Delphi, Siemens, Denso using a sliding hammer
• Universal set OPEL/VAUXHALL ∙ LEXUS
• Contents for the removal depending on the design and spatial conditions: • The extractor system securely grips the supply
– 1 set of special pliers for a secure grip in the and overflow oil line connection
clamping jaw receptacle on the injector • Including 5 injector adapters and sliding hammer
– 2 handles with joint adapter for pulling and twisting the injector • Easy removal of the injectors is possible using a sliding hammer
at the same time. Handles can either be attached on the • Quick assignment of the arm pairs thanks to the instructions provided
inside or outside thread of the supply connection
– 1 Bosch special adapter for a secure encompassing grip of the • Plastic box
• 2-component soft foam insert
injectors and ensures a consistent transfer of power
F • SmartCase (1/3) 165-L
• Safety-Insert-System, 2-component soft foam insert.
Insert also suitable for HAZET Assistent

D

R

C

1 L x W x H è 4 1 è 4
mm
4798-6/8 355 x 235 x 65 8 210763 4798-7/14 14 210756

O

A

U

396 Valid until December 31, 2021 Components and spare parts from page 482 to 490
