Specialty Tools

Engine – Fuel System / Fuel Injection

4591 Pipe stopper set 4797 Injector extractor

• Sealing of pipes and preventing fluids from escaping C Jß
• Application: Sealing pipelines in brake systems, air conditioning systems, power
steering and fuel systems that cannot be secured with a flexible hose clamp
1
5
• Sealing in sizes of 6.3 mm ( ⁄4″) ∙ 8 mm ( ⁄16″) ∙ 10 mm ( ⁄8″) and for
3
double sealing (e.g. banjo connections) in sizes of 10 mm ( ⁄8″) 1 K è 4 G
3
• For e.g. MERCEDES-BENZ CDI engines 611 ∙ 612 ∙ 613 etc.
• Especially suitable for the limited spaces due to the cylinder head cover
4797/2 460 2 121205
• Impact extractor
• M 16 x 1.5
• Striking weight: 1.8 kg
4797-1 460 – 121175
• Injector claw F
• M 16 x 1.5
4797-2 130 – 121182
1 4 • External adapter with inside thread M16 x 1.5 on M27 x 1
• Removal of Bosch injectors with outside thread M27 x 1
4591/4 219650 • In conjunction with impact extractor 4797-1
• Operating mode:
The External Adapter must be used when the injector claw cannot be used,
either because of the vehicle type or because of the lack of space.
2584-1 Intake pipe screwdriver socket Note: after removing the injector with the external adapter, replace the injector
4797-3 50 – 121199 D
• Piezo injector claw
Made in Germany ß b8
• Application: Intake manifold screw connection • Removal of Piezo injectors on MERCEDES-BENZ engines OM 651
• Extra long design • The design of the injector claw, tuned to the injector, ensures
optimal reception of the injector during operation
• With knurling • MERCEDES-BENZ:
• DIN 3124, ISO 2725-1 A-class type 176 ∙ B-class type 246 ∙ C-class type 204, 205
E-class type 212 ∙ S-class type 221, 222 ∙ V-class typ 639, 447
CLA type 117 ∙ GLA type X156 ∙ GLK type X204
CLS type 218 ∙ ML type 166 ∙ SLK/SLC type 172 ∙ GLC type X253
• Operation with the HAZET impact extractor 4797-1
• Inside thread: M16 x 1.5 mm R
4797-9 54.5 – 206667

4797 Thread repair tool set for
injector fastening screw
1 S M N 4 Made in Germany
2584-1 6 210 248 017058 • For MERCEDES-BENZ CDI engines. Suitable for reaming the broken-off
expansion bolt M6 x 1 from the cylinder head without removing the valve cover C
• Enormous money and time saving as the replacement of cylinder head and the
4797 Injector extractor removing of injectors and valve covers is not necessary
• Damaged thread is reworked to M 8 x 1
Contents:
Made in Germany Jß 1 twist drill 6 mm with spacer sleeve
• Application: For disassembly of tight common rail 1 tap M 8 x 1
injectors without removing the cylinder head 1 drill sleeve
1 twist drill 7 mm with spacer sleeve and guide tube
1 knob for screwing
5 threaded inserts M 6 x 1
• SmartCase (1/9) 165-S O
• Safety-Insert-System, 2-component soft
foam insert.
Insert also suitable for HAZET Assistent

A

4797-1

1 L x W x H è 4 U
mm
4797/10 185 x 153 x 52 10 191505
4797-2 4797-3 4797-9
• Threaded inserts ∙ 5 pieces M 6 x 1 for 4797/10
B 4797-M 6 x 1/5 – 5 192441
Components and spare parts from page 482 to 490 Valid until December 31, 2021 395
