Specialty Tools

Engine – Spark and Glow Plug

4760 Glow plug wrench 4760 Glow plug removal set

Made in Germany I c7 C
• With ball clamping to hold the glow plug
• Application: Installing and removing glow plugs (Ä 8 mm)
• On e.g. MERCEDES-BENZ ∙ SMART ∙ VW ∙
FIAT and OPEL/VAUXHALL diesel engines G
• Angular movement ±45°
• American dimensions
• With hinge – for working in areas with restricted
access and for getting around obstructive edges
• Drive with ball race
• Blister packed
• Surface: chrome-plated
• DIN 3124, ISO 2725-1
F

1 S K G H 4 1 L x W x H è 4
mm
4760-2 8 142 11.8 18 118670 4760/6 355 x 235 x 65 6 191642

4760 Glow plug socket pliers 4760 Glow plug repair set D
Made in Germany I Made in Germany
• The pliers’ design is specially adapted to the sockets • Thread repair without having to remove the cylinder head
• Application: Installation and removal of glow plug sockets on diesel engines • To be used together with glow
e.g. MERCEDES-BENZ, VW, AUDI, SEAT, ŠKODA and BMW plug removal set 4760/6
• Offset design for use on glow plug sockets in areas with restricted access • SmartCase (1/9) 165-S
• With recess preventing cable damage • Safety-Insert-System, 2-component soft foam
• Ergonomically shaped HAZET 2-component plastic handle covers (blue/black) insert.
Insert also suitable for HAZET Assistent
R

1 4 1 L x W x H è 4 C
4760-5 089130 mm
• Ripped out threads M8 x 1 are reworked on M10 x 1
• 1 twist drill 6.8 mm with spacer sleeve
4760 Glow plug removal set 1 tap M8 x 1
1 tap M10 x 1
Made in Germany 1 twist drill 9 mm
• Knocking out broken glow plugs Ä 8 – 10 mm 5 threaded inserts M8 x 1
4760-M 8 x 1/9 185 x 153 x 52 9 191536
• Allows time-saving repair without the need to remove the cylinder head • Ripped out threads M10 x 1 are reworked on M12 x 1 O
• Damaged threads are trimmed or renewed/ • 1 twist drill 9 mm with spacer sleeve
reworked (see also 4760-M 8 bis -M 10) 1 tap M10 x 1
• SmartCase (1/3) 165-L 1 tap M12 x 1
• Safety-Insert-System, 2-component soft foam insert. 1 twist drill 11 mm
5 threaded inserts M10 x 1
Insert also suitable for HAZET Assistent
4760-M 10 x 1/9 185 x 153 x 52 9 191529
4760 Disassembly/assembly auxiliary tool

• Prevents the glow and spark plugs from falling down and becoming A
damaged during disassembly/assembly
• Application: Auxiliary tool for safely securing flow and spark
plugs, especially in constricted spaces
• Full rubber design
• Length of 230 mm enables more careful
threading and unthreading

U

1 K 4
B 4760-11 230 222346
