Specialty Tools Specialty Tools

Engine – Spark and Glow Plug Engine – Spark and Glow Plug

4766 Spark plug wrench 4766 Spark plug wrench

Made in Germany I/ c7 C I r7
• With fixing clamp for a firm hold of the spark plugs
• Application: Installing and removing spark plugs (16 mm or ⁄8″)
5
G • On e.g. VW ∙ AUDI ∙ SEAT ∙ ŠKODA ∙ RENAULT ∙ FIAT ∙ FORD ∙ OPEL/
VAUXHALL ∙ BMW ∙ NISSAN ∙ HONDA ∙ MAZDA ∙ MITSUBISHI ∙ KIA ∙ Volvo
• Angular movement ±50°
• American dimensions
• With hinge – for working in areas with restricted
access and for getting around obstructive edges
• Drive with ball race
• Surface: chrome-plated
1 S K G H c 4
• DIN 3124, ISO 2725-1
F 4766-3 14 154 19.1 18 10 199976

4767 AKF Spark plug wrench

Made in Germany I/ c8
• Spring in the joint
• Application: Installing and removing spark plugs (Ä 16 mm = ⁄8˝)
5
• With fixing clamp for a firm hold of the spark plugs
D • Long design
• American dimensions
• Drive with ball race
• Surface: chrome-plated
1 S T K G H c 4 • DIN 3124, ISO 2725-1

4766-1 16 5 ⁄8 270 21.4 18 10 048991
Made in Germany I/ r7
R • 12-point profile enables application of spark plugs
with 6-point and 12-point
• Application: Installing and removing spark plugs (Ä 14 mm)
• Fixing clamp for a firm hold of the spark plug
• On BMW E90 N 54 engine 335 i saloon model year 2006 → ∙ 1 Series (F20) 118i ∙
RENAULT Modus ∙ Twingo ∙ Clio ∙ Kangoo with 1.2 l 16 V engine ∙ PEUGEOT
207 ∙ 307 and CITROËN C4 with 1.4 and 1.6 l 16 V engine ∙ C5 with 2.0 l HPi
engine ∙ MERCEDES-BENZ engine M 156 ∙ engine M 276 ∙ NISSAN Micra ∙
Note ∙ MINI 1.2 – 1.4 l 4-cylinder model year 2007 → ∙ FORD 1.0 EcoBoost
engine ∙ ALFA 1.8 TBI engine ∙ KIA ∙ PORSCHE 911 GT3 model
year 2014 → ∙ 2.9 l ∙ 3 l ∙ 4 l ∙ AUDI 3 l TFSI ∙ VW 3 l TSI
C • Drive with ball race
• DIN 3124, ISO 2725-1

1 S T K G H c 4
4767 A KF 16 5 ⁄8 480 25.5 23 10 049028

2530 Glow plug socket
O Made in Germany

• With ball clamping to hold the glow plug $ 7
1 S K G H c 4 • Application: Installing and removing glow plugs (Ä 10 mm)
• VW ∙ AUDI direct injection engines TDi and
4766-2 14 64 18 17.3 10 087655 MERCEDES-BENZ CDI ∙ SMART
• Angular movement ±45°
• With hinge – for working in areas with restricted
Made in Germany I r7 access and for getting around obstructive edges
A • 12-point profile enables application of 14 mm spark plugs • Drive with ball race
with 6-point and 12-point
• Blister packed
• Surface: chrome-plated
• Application: For 14 mm spark plugs e.g. BMW and MERCEDES-BENZ • DIN 3124, ISO 2725-1
• Fixing clamp for a firm hold and problem-free positioning
and assembly of the spark plug
• Angular movement ±56°
• With hinge – for working in areas with restricted access
and for getting around obstructive edges
• Drive with ball race
U • DIN 3124, ISO 2725-1

1 S K G H c 4
B 2530 10 140 15 18 9 016341
