PRECISION STEEL SQUARE

³ accuracy class 00
³ long side with knife edges on both sides
³ measuring surface lapped
³ high-tensile steel, through hardened
³ DIN 875

Measurement Pieces Weight/g
Code Number
mm U V
1569000501000 1569-50 50 x40 1 35
1569000751000 1569-75 75 x 50 1 60
1569001001000 1569-100 100 x 70 1 126
1569001501000 1569-150 150 x 100 1 293

1570-.../1571-...
ENGINEER STEEL SQUARE
³ 1570: 90° plain blade without stop
³ 1571: 90° blade with stop
³ with exposed try square
³ zinc coated
³ steel

Measurement Pieces Weight/g
Code Number
mm U V
1570001001000 1570-100 100 x 70 6 70
1570001501000 1570-150 150 x 100 6 150
1570002001000 1570-200 200 x 130 6 250
1570002501000 1570-250 250 x 160 6 350
1570003001000 1570-300 300 x 180 6 400
1570004001000 1570-400 400 x 230 6 575
1570005001000 1570-500 500 x 280 6 770
1570006001000 1570-600 600 x 330 1 1000
1570007501000 1570-750 750 x 380 1 1200
1570010001000 1570-1000 1000 x 500 1 1850
11 1571001001000 1571-100 100 x 70 4 105

1571001501000 1571-150 150 x 100 4 235
1571002001000 1571-200 200 x 130 4 350
1571002501000 1571-250 250 x 160 4 475
1571003001000 1571-300 300 x 180 2 550
1571004001000 1571-400 400 x 230 2 800
1571005001000 1571-500 500 x 280 2 1100
1571006001000 1571-600 600 x 330 1 1380
1571007501000 1571-750 750 x 380 1 1660
1571010001000 1571-1000 1000 x 500 1 2220
