P. 355

510-280
               WELDER'S GRIP PLIER

         ³   for clamping of profiles and straps,
            especially appropriate to connect two
            working pieces of the same thickness
         ³   the light metal alloy avoids the adhering
            of welding beads
         ³   the large opening allows a good overview
            during welding
         ³   quick release lever with return spring
         ³   nickel-plated
         ³   jaws made of heavy-duty light metal alloy







           Code      Number      Span Width mm         Radial mm        l/mm        l/Inch     Pieces    Weight/g
                                                                         T           T          U          V
         0510202803000  510-280      0-60                80              280         11         1          790


               511-280
               PIPE WELDERS GRIP PLIER
         ³   for centered clamping of two close-fitting pipes
            for welding, drilling, soldering etc.
         ³   the large opening allows a good overview
            during welding
         ³   quick release lever with return spring
         ³   nickel-plated
         ³   jaws made of ELORA-Chrome-
            Vanadium 31 CrV 3 / 1.2208










           Code      Number      Span Width mm         Radial mm        l/mm        l/Inch     Pieces    Weight/g   08
                                                                         T           T          U          V
         0511102803000  511-280      10-90               90              280         11         1          935


               524-...
               CHAIN GRIP PLIER
         ³   for clamping of any shaped profile,
            especially appropriate in narrow
            and difficult to reach areas like
            oil filters, exhaust pipes, etc.
         ³   ELORA-No. 524E
            is an extension as well as
            spare chain at the same time
         ³   quick release lever
            with return spring
         ³   nickel-plated
         ³   jaws made of ELORA-Chrome-Vanadium
            31 CrV 3 / 1.2208




           Code      Number         for ø up to mm          l/mm                Pieces              Weight/g
                                                             T                    U                   V
         0524002503000  524-250       150                    250                  1                   930
         0524400003000  524-E    spare and extension chain   480                  1                   315
