Socket with resin protector
to prevent damage on aluminum wheels

No-protector type
4A-17LLN
Resin protector
Resin protector
Power wrench (for truck wheel)
17
Electroless plating 4A-17LLN 17 Color-coded
Electroless plating
Color-coded
Avoid any
19
for easy
Appearance quality & interference with 19 for easy
size selection.
anti-rust improved size selection.
21
slim design 21
Standard equipment for preventing an aluminum wheel against THIN TYPE WHEEL NUT PROTECTOR LONG SOCKET SET for IMPACT WRENCH (with SOCKET HOLDER)
scratches. A rubber cushion inside a socket protects wheel nut
against possible scratches.
Models HAP403LLN
12.7 6 Contents 3 Items
mm
1/2 Descriptions Models
THIN TYPE WHEEL NUT PROTECTOR
LONG SOCKET for IMPACT WRENCH 4AP- 17LLN, 19LLN, 21LLN
※ The specialized Pin and o-ring is available for separate purchase.
● With socket holder (4 items type )
● Package size : w160 × d145 × h30mm
● Weight : 0.70kg ● Qty./Carton : 1

HAP403LLN
THIN TYPE WHEEL NUT PROTECTOR LONG SOCKET for IMPACT WRENCH

Across
Flat Dimensions (mm) Qty./Carton Weight
Models (mm) (g)
S D1 D2 L1 (Generally) (Store Center)
4AP-17LLN 17 25.0 23.7 21.0 10 6 220
4AP-19LLN 19 27.0 25.7 23.0 10 6 225
4AP-21LLN 21 28.8 27.5 25.0 10 6 230
※ The specialized Pin and o-ring is available for separate purchase.
※ D2 is a dimension when protector is removed.
● 6 Points strong drive 3FTJO1SPUFDUPS
4AP-17LLN 4AP-19LLN 4AP-21LLN - Rubber cushion

% %
Example ̨

■ Pin/O-ring compatible chart
Models 4A- 17LLN ～ 22LLN
Pin P3020S
O-ring RP20S
※ Within a plastic bag (10 pcs./pkg.)
CAUTION
● If excessive force is applied to thin type socket, earlier breakage or crack might be caused.

※ A protector cannot be used with 4A-17LN, 19LN, 21LN, 4A-17LLN, -19LLN, -21LLN because
of dimension difference.
PROTECTOR FOR THIN WALL WHEEL NUT SOCKET

Models RK-4AP17LLN （Across Flat 17 mm）
RK-4AP19LLN （Across Flat 19 mm）
RK-4AP21LLN （Across Flat 21 mm）
RK-4AP17LLN RK-4AP19LLN RK-4AP21LLN
※ With a plastic bag

WARNING
394 'PS JNQBDU XSFODIFT ● Use right size o-ring and pin securely fixed.
● O-ring and pin are consumptive parts. Replace those which are deteriorated or worn.
