THIN TYPE WHEEL NUT SOCKET SET for IMPACT WRENCH (with SOCKET HOLDER) Specialized for tightening and loosening automobile wheel nuts.
A thin shape designed for easy to attaching and detaching a wheel
nut. The rubber cushion prevents damage for lesser damage of
Models HA404N wheel (for aluminum wheels, etc.).

Contents 4 Items 12.7 6
Descriptions Models mm
THIN TYPE WHEEL NUT 1/2
SOCKET for IMPACT WRENCH 4A- 17N, 19N, 21N, 22N
● 6 Points strong drive
● With socket holder (4 items type )
● Package size : w195x d93x h30mm
● Weight : 0.58kg
● Qty./Carton : 1

HA404N

Models HA403N
Contents 3 Items
Descriptions Models
THIN TYPE WHEEL NUT
SOCKET for IMPACT WRENCH 4A- 17N, 19N, 21N
● 6 Points strong drive
● With socket holder (4 items type )
● Package size : w195x d93x h30mm
● Weight : 0.43kg
● Qty./Carton : 1
HA403N

THIN TYPE WHEEL NUT SOCKET for IMPACT WRENCH

Across
Flat
Models (mm) Dimensions (mm) Qty./Carton Weight
(g)
S D1 D2 L1 (Generally) (Store Center)
4A-17N 17 24.0 23.5 22 10 6 85
4A-19N 19 26.0 24.0 24 10 6 90 4A-17N 4A-19N 4A-21N 4A-22N
4A-21N 21 27.5 24.0 26 10 6 100
4A-22N 22 29.5 24.0 27 10 6 110
● 6 Points strong drive Rubber cushion

■ Pin/O-ring compatible chart
Models 4A- 17N ～ 22N
Pin P3020S
O-ring RP20S
※ Within a plastic bag (10 pcs./pkg.)

CAUTION
● If excessive force is applied to thin type socket, earlier breakage or crack might be caused.

Pre-set torque wrenches for vehicle
TORQUE WRENCH for WHEEL NUT
T4MP103
Models T4MP85, T4MP103, T4MP108 T4MP85
Turn to P405 for more information.

'PS JNQBDU XSFODIFT WARNING
● Use right size o-ring and pin securely fixed. 391
● O-ring and pin are consumptive parts. Replace those which are deteriorated or worn.
