FLEX PLUG SOCKET (6pt. with MAGNET)
9.5

Across mm 3FP-20.8
3/8
Flat Dimensions (mm) Qty./Carton Weight
Models (mm) (g)
S D1 D2 L1 L d (Generally) (Store Center) 6
3FP-16 16 21.3 20 6.5 382 9.5 1 1 375 3FP-16
3FP-20.8 20.8 26.5 20 6.5 379 9.5 1 1 495
● Thin wall
● Only for spark plug Example
Magnet
CAUTION
● Thin-wall type for spark plug

PLUG SOCKET (6pt. with MAGNET) Convenient for fast-turning with knurling design.
12.7 6
Across
Flat Dimensions (mm) Qty./Carton Weight mm
Models (mm) (g) 1/2
S D1 D2 L1 L d (Generally) (Store Center)
4P-16 16 21.0 20.6 6.5 64 12 10 6 115
4P-18 18 23.5 22.0 6.5 64 12 10 6 130
4P-20.8 20.8 26.5 24.5 6.5 64 17 10 6 170
● 6 Points strong drive Magnet 4P-20.8
● Thin wall
● Only for spark plug Example

4P-16

CAUTION
● Thin-wall type for spark plug

SENSOR SOCKET (6pt.) Socket for tightening and loosening sensors of electronically
control engine.
(Water temperature sensor, oil pressure sensor, etc.)
Across Knurling finished, convenient for quick turning.
Flat Dimensions (mm) Qty./ Weight
Models (mm) Carton (g)
S D A L d (Generally) 9.5 6
3SEN-17 17 24 35 60 15 10 100
3SEN-19 19 26 35 60 17 10 110 mm
3/8
3SEN-22 22 30 35 60 19 10 140
3SEN-24 24 32 35 60 20 10 160
3SEN-26 26 35 35 60 22 10 180
3SEN-27 27 36 35 60 22 10 190
● 6 Points strong drive

3SEN-27
3SEN-19

Example

8BUFS UFNQFSBUVSF TFOTPS 0JM QSFTTVSF TFOTPS
"DSPTT 'MBU PS PS NN PG GPS XBUFS UFNQFSBUVSF TFOTPST
"DSPTT 'MBU PS PS NN PG GPS PJM QSFTTVSF TFOTPS

CAUTION
● Depending on car and engine model, sensor sockets and slit sockets may not be
able to use.

'PS IBOE UPPM 8JUI NBHOFU CAUTION
● Do not use with power tools. 389
