Wheel nut socket (outer and inner) for large buses and trucks. IMPACT SOCKET SET (for TRUCK WHEEL)
Easy to organize and get access to products with design case.

19.0 For bus/track Models A609T
mm Contents 9 Items
3/4
Descriptions Models
4 6 BUDD WHEEL SOCKET (for
OUTER NUT of TRUCK WHEEL) 6A- 32T, 33T, 35T, 38T, 41T
BUDD WHEEL SOCKET (for
INNER NUT of TRUCK WHEEL) 6A- 17B, 19B, 20B, 21B
● 6 Points strong drive
● For tightening/loosening outer nut and inner nut
A609T ● Package size : w370x d160x h125mm
● Weight : 6.3kg
● Qty./Carton : 1

Socket for tightening/loosening of outer nut for bus and truck. BUDD WHEEL SOCKET (for OUTER NUT of TRUCK WHEEL)
Size can handle from medium-sized car to large car.

6 Across Dimensions (mm) Qty./
Flat
Models (mm) Carton Weight
(g)
S D1 D2 L1 L d (Generally)
6A-30T 30 46 44 22 75 25 5 620
0VUFS OVU 6A-32T 32 48 44 22 75 25 5 650
6A-33T 33 49 44 28 75 25 5 640
6A-35T 35 50 44 28 75 25 5 630
6A-41T 6A-38T 38 55 48 28 75 30 5 760
6A-41T 41 58 48 28 75 35 5 755
■ Pin/O-ring compatible chart ● 6 Points strong drive
Models 6A- 30T ～ 35T 38T, 41T ● For tightening/loosening outer nut
Pin PIN5039S PIN5043S
CAUTION
O-ring RINGW28S RAS326S ● This thin-wall budd wheel socket is only for tire, please do
※ Within a plastic bag (10 pcs./pkg.) not use on other applications.
Socket for tightening/loosening of inner nut for bus and truck. BUDD WHEEL SOCKET (for INNER NUT of TRUCK WHEEL)
Size can handle from medium-sized car to large car.
4 *OOFS OVU Across Dimensions (mm) Qty./
Flat
Models (mm) Carton Weight
(g)
S D1 D2 L1 L (Generally)
6A-17BA 17 38 38 20 55 5 355
6A-19BA 19 40 38 20 55 5 375
6A-21BA 6A-20BA 20 41 38 20 55 5 385
■ Pin/O-ring compatible chart 6A-21BA 21 42 38 20 55 5 395
Models 6A- 17BA ～ 21BA ● For tightening/loosening inner nut
Pin P4033S
O-ring RAS322S ※ This product is registered design.
※ Within a plastic bag (10 pcs./pkg.) CAUTION
● Hold square inner nut securely to use a budd wheel socket.
Socket for tightening/loosening of inner nut for bus and truck. BUDD WHEEL SOCKET (for INNER NUT of TRUCK WHEEL)
Size can handle from medium-sized car to large car.
*OOFS OVU
4 Across Dimensions (mm) Qty./Carton
Flat
Models (mm) Weight
(g)
S D1 D2 L1 L d (Generally) (Store Center)
6A-17B 17 38 38 21 66 27 5 5 365
6A-19B 19 38 38 21 66 28 5 5 340
6A-19B 6A-20B 20 38 38 21 66 31 5 5 315
■ Pin/O-ring compatible chart 6A-21B 21 40 38 21 66 31 5 5 340
Models 6A- 17B ～ 21B ● For tightening/loosening inner nut
Pin PIN5033S
O-ring RINGT32S CAUTION
※ Within a plastic bag (10 pcs./pkg.) ● Hold square inner nut securely to use a budd wheel socket.

WARNING
398 'PS JNQBDU XSFODIFT ● Use right size o-ring and pin securely fixed.
● O-ring and pin are consumptive parts. Replace those which are deteriorated or worn.
