BRAKE: SERVICE TOOLS

Dial Test Indicator Sets SHOP
GA3634 Ball Joint/Disc Brake Test Indicator Set
• All-purpose indicator set
• Perfect for general use
• Indicator with 0–1ʺ range and .0005ʺ graduations
• Easy-to-read white on black dial face
• GA3640 uses a fixed magnetic base
• GA3645 uses a conforming magnetic base for more mounting options
• GA3634 uses locking pliers and a flexible gooseneck for non-magnetic GA3634
applications and difficult areas
• Ideal for brake and undercar work

Brake Drum/Rotor Gauges
DG530 Digital Drum Gauge
• Measures automotive and heavy-duty brake drums DG530
• Pointed anvils and 4-1/4ʺ long arms allow increased measurement accuracy
and coverage
• Selectable depth stops for easier use EQUIPMENT
• 6–20.65ʺ (150–515 mm) range: .0005ʺ (.01 mm) graduations
®
RG430A Digital Rotor Gauge (Blue-Point )
• Measures brake rotors and ball joints
• Pointed anvil and 3-1/2ʺ long arms for increased measurement accuracy and
coverage
• Selectable depth stops for easy use
• 0–5-1/2ʺ (0–140 mm) range; .0005ʺ (.01 mm) graduations
• Easy to read digital display with inch/metric conversion RG430A
CAL6EBR 6ʺ Electronic Brake Rotor Caliper
• Specifically designed for performing inspection work on brake rotors
• The pointed contact enables a user to accurately locate the deepest pits on
a brake rotor
• Having the most accurate dimensions prevents over-machining the brake rotor
during the reconditioning process
• Tool has range that a micrometer cannot handle (large rotors in the heavy-duty
truck market and large agricultural machinery)
• The long jaws enable measurements deep into the rotor to achieve a clear CAL6EBR
profile of the rotor surface

Truck Brake Tools
BTGHD9 Heavy-Duty Brake Lining Gauge
• Accurately confirm brake lining thickness for customers and DOT inspections sheets
• Gauge tool consisting of 9 blades of different sizes ranging between 6–22 mm
(0.24–0.87ʺ)
• Made of durable stainless steel with both the standard and metric sizes laser-etched
on the face BTGHD9

Emergency Brake
BCT1050 Parking Brake Cable Coupler Removal Tool
• Used on light duty trucks, SUVs and vans with drum or disc brakes
• Cushioned grips for comfort
• Heat treated for durability
• Angled head for accessibility
• Overall length is 14ʺ for adequate leverage
• Use to safely separate the mid-cable coupler from the cable end BCT1050
®
®
• Use on Ford , GM , Dodge light trucks, SUVs and vans from the late 1980s to current
®

809
• Follow all safety messages in instructions
• Read safety precautions on pages W1 to W4
