MarGage 408 / 409

Rectangular Gage Block Set made of Steel

FEATURES

• Vertical arrangement to save
space
Calibration class K
As primary factory standard,
particularly for the calibration of
subsidiary test laboratories, e.g.
for gage blocks of lower tolerance
classes.
408 409
Tolerance class 0
For maximum accuracy
requirements. To be used as basic
standards in test laboratories TECHNICAL DATA
and precision inspection rooms,
where other gage blocks and high Order no. Product type Quantity per set Tolerance class Nominal sizes Increment Number
accuracy measuring instruments Pieces mm mm
are calibrated.
4800020 408 111 0 0.5 - 1
1.001 – 1.009 0.001 9
Tolerance class 1
For high accuracy requirements. Includes Mahr calibration 1.01 – 1.49 0.01 49
As reference gage block for the certificate 1 – 24.5 0.5 48
measuring room. Designed to 25 – 100 25 4
perform particularly accurate 4800021 408 111 1 0.5 - 1
measurements. For setting 1.001 – 1.009 0.001 9
indicating measuring instruments. Includes Mahr calibration 1.01 – 1.49 0.01 49
For checking precision gages. certificate 1 – 24.5 0.5 48
25 – 100 25 4
Tolerance class 2 4800022 408 111 2 0.5 - 1
For checking production gages of 1.001 – 1.009 0.001 9
quality IT 6 and IT 7. For setting Includes Mahr calibration 1.01 – 1.49 0.01 49
indicating measuring instruments certificate 1 – 24.5 0.5 48
and for checking accurate 25 – 100 25 4
dimensions in the jig and tool 4800027DKS 408 111 K 0.5 - 1
industry. 1.001 – 1.009 0.001 9
Includes DAkkS calibration 1.01 – 1.49 0.01 49
certificate 1 – 24.5 0.5 48
• Package contains: wooden case 25 – 100 25 4
with clear labeling strips, Mahr 4800030 409 121 0 0.5 - 1
calibration certificate 1.001 – 1.009 0.001 9
• Coefficient of linear Includes Mahr calibration 1.01 – 1.49 0.01 49
expansion: 11.5 x 10 K – 1 certificate 1.6 – 1.9 0.1 4
– 6
1 – 24.5 0.5 48
30, 40, 60, 70 ,80 ,90 10 6
25, 50, 75, 100 25 4
4800031 409 121 1 0.5 - 1
1.001 – 1.009 0.001 9
Includes Mahr calibration 1.01 – 1.49 0.01 49
certificate 1.6 – 1.9 0.1 4
1 – 24.5 0.5 48
30, 40, 60, 70 ,80 ,90 10 6
25, 50, 75, 100 25 4
4800032 409 121 2 0.5 - 1
1.001 – 1.009 0.001 9
Includes Mahr calibration 1.01 – 1.49 0.01 49
certificate 1.6 – 1.9 0.1 4
1 – 24.5 0.5 48
30, 40, 60, 70 ,80 ,90 10 6
25, 50, 75, 100 25 4
4800033DKS 409 121 K 0.5 - 1
1.001 – 1.009 0.001 9
Includes DAkkS calibration 1.01 – 1.49 0.01 49
certificate 1.6 – 1.9 0.1 4
1 – 24.5 0.5 48
30, 40, 60, 70 ,80 ,90 10 6
25, 50, 75, 100 25 4

ACCESSORIES
Order no. Product name Product
type

4800130 Maintenance accessories 424
4800140 Optical flat, Ø = 45 mm 421
4800142 Wooden tongs, single, to prevent heat transfer when handling gage blocks 423

472 MarGage | Standards, Gages and Gage Blocks
